LYNX ACSR From New Baofeng

Name: LYNX ACSR From New Baofeng
Brand: New Baofeng
SKU: 119879293
Availability: InStock

US$ 1 - 500 MOQ: 500 Meters

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

New Baofeng

Model Number:

ACSR LJ LGJ LGJF JL JLHA2 JLHA1

Hebei New Baofeng Wire & Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name New Baofeng

Model Number ACSR LJ LGJ LGJF JL JLHA2 JLHA1

Insulation Material Other, Aluminium

Type High Voltage

Application Overhead

Conductor Material Aluminum

Jacket Other, non

Specifications

ACSR
1. passed CE,ISO,CCC,PCCC...certificate
2.sell well in Europe, America, Asia

ACSR

Type of conductor:

1 AAC:All Aluminium Conductors

ASC:Aluminium Stranded Conductors

2 AAAC:All Aluminium Alloy Conductors

AASC:Aliminium Alloy Stranded Conductors

3 ACSR:Aluminium Conductor Steel Reinforced

ACSR Technical Characteristics Based on Standard BS 215-2

Code name	Nominal aluminium area	Stranding and wire diameter		Sectional area of aluminium	Total sectional area	Approx. overall diameter	Approx. mass	Calculated D.C. resistance at 20^oC	Calculated breaking load
	Nominal aluminium area	Al	Steel	Sectional area of aluminium	Total sectional area	Approx. overall diameter	Approx. mass	Calculated D.C. resistance at 20^oC	Calculated breaking load
	mm²	No./mm		mm²	mm²	mm	kg/km	Ω/km	kN
RABBIT	50	6/3.35	1/3.35	52.88	61.7	10.05	214	0.5426	18.35
DOG	100	6/4.72	7/1.57	105	118.5	14.15	394	0.2733	32.7
WOLF	150	30/2.59	7/2.59	158.1	194.9	18.13	726	0.1828	69.2
DINGO	150	18/3.35	1/3.35	158.7	167.5	16.75	506	0.1815	35.7
LYNX	175	30/2.79	7/2.79	183.4	226.2	19.53	842	0.1576	79.8
ZEBRA	400	54/3.18	7/3.18	428.9	484.5	28.62	1621	0.0674	131.9

AAAC Technical Characteristics Based on Standard BS 3242

Code name	Nominal aluminium area	Stranding and wire diameter	Sectional area	Approx. overall diameter	Approx. mass	Calculated D.C. resistance at 20^oC	Calculated breaking load
Code name	mm²	No./mm	mm²	mm	kg/km	Ω/km	kN
ALMOND	25	7/2.34	30.1	7.02	82	1.094	8.44
CEDAR	30	7/2.54	35.47	7.62	97	0.9281	9.94
FIR	40	7/2.95	47.84	8.85	131	0.688	13.4
HAZEL	50	7/3.30	59.87	9.9	164	0.5498	16.8
OAK	100	7/4.65	118.9	13.95	325	0.2769	33.3
ASH	150	19/3.48	180.7	17.4	497	0.183	50.65
ELM	175	19/3.76	211	18.8	580	0.1568	59.1
UPAS	300	37/3.53	362.1	24.71	997	0.09155	101.5
