Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > TOP-Quality Low Resistance & High Tension Stranded Aluminum Steel Reinforced Conductor ACSR CABLE

TOP-Quality Low Resistance & High Tension Stranded Aluminum Steel Reinforced Conductor ACSR CABLE

Negotiable MOQ: 1000 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

NBF

Model Number:

High Voltage

Contact Supplier Request Quote Chat Now

Hebei New Baofeng Wire & Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name NBF

Model Number High Voltage

Insulation Material XLPE

Type High Voltage

Application Other, Industrial,Construction Power Station,Industrial ,Underground

Conductor Material Other, copper or aluminium

Jacket PVC

Specifications

1 IEC, ASTM, DIN, BS standard
2 ISO,CCC certification
3 Response within 12 hours
4 Free Sample
5 On time delivery

TOP-Quality low resistance & high tension stranded aluminum steel reinforced conductor ACSR CABLE

BARE ACSR (ALUMINUM CONDUCTOR STEEL REINFORCED )

Specification of acsr cable

ACSR bare conductor meets or exceeds the following ASTM specifications:

B-230 Aluminum Wire, 1350-H19 for Electrical Purposes
B-231 Aluminum Conductors, Concentric-Lay-Stranded
B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR)
B-341 Aluminum-clad Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AW)
B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)
B-500 Zinc Coated and Aluminum Coated Stranded Steel Core for Aluminum Conductors, Steel Reinforced (ACSR)

Construction of acsr cable

Aluminum alloy 1350-H-19 wires, concentrically stranded about a steel core. Core wire for ACSR is available with class A, B, or C galvanizing; ""aluminized"" aluminum coated (AZ); or aluminum-clad (AW) - please see our ACSR/AW spec for more information. Additional corrosion protection is available through the application of grease to the corer or infusion of the complete cable with grease.

Technical Data of acsr cable

ACSR IEC 61089

Code Number	Stranding& Wire Diameter		Approx	Sectional Area			Approx Weight	Breaking Load	DC Resistance
	Stranding& Wire Diameter		Overall	Sectional Area			Approx Weight	Breaking Load	DC Resistance
	Al	Steel	Diameter	Al	Steel	Total
	mm	mm	mm	mm²	mm²	mm²	Kg/km	KN	Ohm/km
16	6/1.84	1/1.84	5.53	16	2.67	18.7	64.6	6.08	1.7934
25	6/2.30	1/2.30	6.91	25	4.17	29.2	100.9	9.13	1.1478
100	6/4.61	1/4.61	13.8	100	16.7	117	403.8	34.33	0.2869
125	18/2.97	1/2.97	14.9	125	6.94	132	397.9	29.17	0.2304
160	18/3.36	1/3.36	16.8	160	8.89	169	509.3	36.18	0.18
250	22/3.80	7/2.11	21.6	250	24.6	275	880.6	68.72	0.1154
400	54/3.07	7/3.07	27.6	400	51.9	452	1510.3	123.04	0.0723
450	54/3.26	7/3.26	29.3	450	58.3	508	1699.1	138.42	0.0643
500	54/3.43	7/3.43	30.9	500	64.8	565	1887.9	153.8	0.0578
560	54/3.63	19/2.18	32.7	560	70.9	631	2103.4	172.59	0.0516
630	54/3.85	19/2.31	34.7	630	79.8	710	2366.3	191.77	0.0459
710	54/4.09	19/2.45	36.8	710	89.9	800	2666.8	216.12	0.0407
800	72/3.76	7/2.51	37.6	800	34.6	835	2480.2	167.41	0.0361
900	72/3.99	7/2.66	39.9	900	39.9	939	2790.2	188.33	0.0321

Packing And Transportation

Wooden Cable Packing Drums

We offer a wide range of Wooden Cable Drum that are specially designed to meet the requirements of cable packing . With the assistance of these cable drums the cables can be easily transported to various destinations without causing any defect to the cables.
