Medium Voltage Steel Tape /steel Wire Armour Power Cable 6kv,10kv, 20kv, 33kv Power Cable XLPE Insulated PVC Cover

Name: Medium Voltage Steel Tape /steel Wire Armour Power Cable 6kv,10kv, 20kv, 33kv Power Cable XLPE Insulated PVC Cover
Brand: New Baofeng
SKU: 119878367
Availability: InStock

Medium Voltage Steel Tape /steel Wire Armour Power Cable 6kv,10kv, 20kv, 33kv Power Cable XLPE Insulated PVC Cover thumbnail-1

Medium Voltage Steel Tape /steel Wire Armour Power Cable 6kv,10kv, 20kv, 33kv Power Cable XLPE Insulated PVC Cover photo-1

US$ 22 - 80 MOQ: 1500 Meters

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

New Baofeng

Model Number:

YJV,YJV22,YJV32

Contact Supplier Request Quote Chat Now

Hebei New Baofeng Wire & Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Xingang Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name New Baofeng

Model Number YJV,YJV22,YJV32

Insulation Material XLPE

Type Medium Voltage

Application Power Station

Conductor Material Copper

Jacket PVC

Medium voltage steel tape /steel wire armour power cable 6kv,10kv, 20kv, 33kv XLPE insulated PVC cover

Product standard

The product is manufactured according to the standard of GB/T12706-2002 “Extruded solid dielectric power cables for rated voltages from l KV (Um=1.2KV) to 35KV (Um=40.5KV)”or IEC, BS, DIN and ICEA upon request.

Operating characteristics

Rated power-frequency voltage U₀/U: 3.6/6KV~26/35KV.

Max. Permissible continuous operating temperature or conductor:90℃.

Max. short-circuit temperature of conductor shall not exceed 250℃. (5s maximum duration)

The ambient temperature under installation should not below 0℃.

The bending radius of a single-core cable should not less than 20 times of the cable diameter.

The bending radius of a three-core cable should not less than 15 times of the cable diameter.

Type	Designation	Application
YJV	Copper conductor, XLPE insulated and PVC sheathed power cable.	For laying indoors, in tunnel or cable trench, unable to bear external mechanical forces, Single core cable in magnetic duct is not permissible.
YJLV	Aluminum conductor, XLPE insulated and PVC sheathed power cable.
YJY	Copper conductor, XLPE insulated and PE sheathed power cable.
YJLY	Aluminum conductor, XLPE insulated and PE sheathed power cable.
YJV22	Copper conductor, XLPE insulated, steel tape armored and PVC sheathed power cable.	For laying indoors, in tunnel, cable trench, or direct in ground, able to bear external mechanical forces, but unable to bear large pulling force.
YJLV22	Aluminum conductor, XLPE insulated, steel tape armored and PVC sheathed power cable.
YJV23	Copper conductor, XLPE insulated, steel tape armored and PE sheathed power cable.	For laying indoors, in tunnel, cable trench, or direct in ground, able to bear external mechanical forces, but unable to bear large pulling force
YJLV23	Aluminum conductor, XLPE insulated, steel tape armored and PE sheathed power cable.
YJV32	Copper conductor, XLPE insulated, steel wire armored and PVC sheathed power cable.	For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling force.
YJLV32	Aluminum conductor, XLPE insulated, steel wire armored and PVC sheathed power cable.
YJV33	Copper conductor, XLPE insulated, steel wire armored and PE sheathed power cable.
YJLV33	Aluminum conductor, XLPE insulated, steel wire armored and PE sheathed power cable.
