Help Center300 / 300V to 26 / 35KV Copper Core Pvc Insulated Flame Retardant Ables 105 C
Related Products
-
GB Middle Voltage 300 / 300V to 26 / 35KV Non - Halogen Low Smoke Flame Retardant CablesUS$ 1 - 500MOQ: 500 Meters -
High Voltage 300V Electrical Aluminlum Core Pvc Insulated Flame Retardant CablesUS$ 1 - 500MOQ: 500 Meters
-
Railway Flame Retardant Cable IEC60332 PE Insulated, PVC Sheathed Flame Retardant Cables 90C 35KV for RailwayUS$ 1 - 500MOQ: 500 Meters
-
Pvc Flame Retardant Cables Copper Core PE Insulated, PVC Sheathed Flame Retardant Cables 26 / 35KV for ElectricalUS$ 1 - 500MOQ: 500 Meters
-
Underground Flame Retardant Cables IEC60332 Copper Core PVC Insulated Rated Voltage 300VUS$ 1 - 500MOQ: 500 Meters
Specifications
pvc insulated flame retardant cablesEnterprise standard. At the same time, apart from implementing IEC60332 orGB/T18380-2001
pvc insulated flame retardant cables
- Usage
This product is suitable for use in all places using non-com-bastion-retardant type power cable, electrical equipment-use wire and cable and all corresponding products and at the same time requires combustion-retardant environment and conditions.
- Property for Use
1.Rated voltage(U0/U), from 300/300V to 26/35KV according to different kinds of product series.
2.The max. word temperature of cable for a long period are:70°C, 90°C and 105°C.
3.For short circuit(5s), the max. work temperature of conductor does not exceed 160°C for 70°C;250°C for 90°C.
4.The temperature for laying cable is not less than 0°C.
5.Cable bend radius implements corresponding non-com-bastion-retardant cable standard stipulation.
6.Combustion-retardant characteristics can be divided into categories A and C(category B is not recommended).
a.ZC-type combustion-retardant cable is used in general combustion-retardant places requiring IEC60332-3C category.
b.ZA-type combustion-retardant cable is used in combustion-retardant places requiring relatively harsh IEC60332-3A category.
c.Single cable should reach the requirement of IEC60332-1(2)non-burning, that is, self-extinguishing nature. Multi-cable or a bundle of cable will only burn in a certain scope after reaching the IEC60332-3 standard and will extinguish itself.
- Scope of Application
Fixed or movable laying in power installation, instrument & meters, etc.
