Specifications
1 Purity raw material2 VDE,UL,CCC,ROHS,CE certificate
3 Free Samples
4 Professional QC inspection
5 More than 12 colour
hot sale pvc or polychloroprene rubber insulation super flexible welding cable electrical wires
1.Rubber/PVC Welding Cable
2.10-120mm2
3.Copper or CCA Welding Cable
4.10 years OEM Welding cable
5.ISO,VDE,ROHS,REACH..
10mm2 Welding Cable
16mm2 Welding Cable
25mm2 Welding Cable
35mm2 Welding Cable
50mm2 Welding Cable
70mm2 Welding Cable
95mm2 Welding Cable
120mm2 Welding Cable
Descriptions:
1.Standard
the welding cable can be produced according to the standard 245 IEC 81,ICEA S-75-381
2.Specific Property for Using
(1).The cable can be used in the connectors of electric weld and pliers of the electrical welding whose toward earth voltage of the low voltage is not more than AC 200 V and the pulsant DC peak value is 400V.
(2).The long-time permissible working temperature of cable is not more than 65.
3.Name and IEC Standard
(1).Rubber Sheathed Welding Cable 245 IEC 81
(2).Rubber Sheathed Welding Cable 245 IEC 82,which is made of chloroperene or the composite stretchy materials.
4. Conductor Materials: Copper, Tinned Copper or CCA
5. Jacket: Rubber or PVC
6. Applications: For Welding Machines and so on
7.The general data of the cable 245 IEC 81 and 245 IEC 82
Conductor Nominal Section (mm2) |
Conductive Core |
Thickness of Section Sheath (mm) |
Average Outer Diameter (mm2) |
200C Conductor Resistance≤(Ω/km) |
|
Number/Diameter of Core(mm) |
Min |
Max |
|||
10 |
322/0.20 |
1.8 |
7.5 |
9.7 |
1.91 |
16 |
513/0.20 |
2.0 |
9.2 |
11.5 |
1.16 |
25 |
798/0.20 |
2.0 |
10.5 |
13.0 |
0.758 |
35 |
1121/0.20 |
2.0 |
11.5 |
14.5 |
0.536 |
50 |
1596/0.20 |
2.2 |
13.5 |
17.0 |
0.379 |
70 |
2214/0.20 |
2.4 |
15.0 |
19.5 |
0.268 |
95 |
2997/0.20 |
2.6 |
17.0 |
22.0 |
0.198 |
120 |
1702/0.30 |
2.8 |
19.0 |
24.0 |
0.161 |
150 |
2135/0.30 |
3.0 |
21.0 |
27.0 |
0.129 |
185 |
1443/0.40 |
3.2 |
22.0 |
29.0 |
0.106 |
