Bucket Elevator,elevator,elevator Conveyor

US$ 1 - 100 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Bucket Conveyor

Material:

Stainless Steel

M&J Machinery Engineer Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai etc.

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Bucket Conveyor

Material Stainless Steel

Material Feature Heat Resistant

Structure Belt Conveyor

Load Capacity made to order

Place of Origin Jiangsu, China

Brand Name MJ

Model Number DTDG

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Bucket Elevator
belt type
made to order
delivery time:15 days after advanced payment
lift material vertically

DTG Type Bucket Elevator Technical Data List
Model		26/9	26/13	26/15	36/18	36/20	36/23	36/28	41/23	41/28	41/32
Bucker Dimension (mm)		90x75	130x110	150x125	180x125	200x125	230x125	280x140	230x140	280x140	320x140
Lifting Volume (m³h)	Granule	5.42	11.49	15.06	25.1	27.89	37.42	51	55.82	67.8	77.5
Lifting Volume (m³h)	Powder	4.7	9.96	13.06	21.73	24.15	32.4	44.1	48.17	58.65	67
Top Wheel Rotating Speed r/min	Granule	81
Top Wheel Rotating Speed r/min	Powder	70
Bucket Space(mm)		350							300
Lifting Height (m)		10 to 40
Motorkw		2.2 to 22

DTG Type Bucket Elevator Technical Data List
Model		48/33	48/38	50/42	60/32	60/38	60/42	60/48
Bucket Dimension (mm)		330x140	380x150	420x150	320x190	380x200	420x200	480x200
Lifting Volume (m³h)	Granule	80.8	99.7	115	133	190.1	210.1	240.2
Lifting Volume (m³h)	Powder	69.35	85.57	98.66	114	162.88	180	205.74
Top Wheel Rotating Speed r/min	Granule	70
Top Wheel Rotating Speed r/min	Powder	60
Bucket Space(mm)		300
Lifting Height(m)		10 to 40
Motorkw		2.2 to 22
