Specifications
1 IEC, ASTM, DIN, BS standard2 ISO,CCC certification
3 Response within 12 hours
4 Free Sample
5 On time delivery
armoured 12 core Flame retardant fiber optic side glow cable prices
Characteristics of product:
1.structure with aluminium tape against moisture, corrugated steel tape as armour,loose tube stranding and double sheaths;
2.loose tube material has good hydrolysis resistance performance and high strength;
pact structure, excellent water-blocking performance;
4.strict manufactureing processes.good mechanical performance and environmental properties.
Applications:
buried,cable trench,etc;
relay communication system;
core network, metropolitan area network and access network etc.
Temperature:
operating temperature:-40°C~+70°C
Standards:
IEC811,IEC60794,IEC60793
Optional:
1.the structure diameter can be designed for customers;
2.to design flame resistance, anti-rodent, anti-ant cable according to the customers' demands.
Structural parameters:
| fiber count |
nominal diameter (mm) |
nominal weight (kg/km) |
permitted tensile LT/ST(N) |
permitted crush LC/SC (N) |
bend radius static state/dynamic state (mm) |
| 2-36 | 14 | 211 | 600/1500(1000/3000) | 300/1000(1000/3000) | 12.5D/25D |
| 38-60 | 15.2 | 238 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 62-72 | 15.8 | 249 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 74-96 | 17.3 | 295 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 98-120 | 18.8 | 336 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 122-144 | 20.3 | 390 | 1000/3000 | 1000/3000 | 12.5D/25D |
| 146-216 | 20.5 | 409 | 1000/3000 | 1000/3000 | 12.5D/25D |
