Fire Resistance Halgen Free Low Smoke Control Cable, PVC Shieled Flexible Control Cable
Negotiable
MOQ: 1000 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
New baofeng
Model Number:
fire resistance halgen free low smoke control cable, PVC shieled flexi
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IEC 60092 -350 IEC 60092 - 376 High Voltage Electrical Xlpe Power CableUS$ 1 - 2MOQ: 500 Meters -
2014 New 450/750V PVC Copper Insulated Armoured Control Cable Made in ChinaUS$ 1 - 2MOQ: 1000 Meters
-
Shielded Control Cable Made in China/priceUS$ 1 - 2MOQ: 1000 Meters
-
State GRID Copper Conductor PVC Sheathed Low Voltage Control CableNegotiableMOQ: 1000 Meters
-
450/750V 0.6/1KV Control Cable Made in ChinaUS$ 1 - 2MOQ: 1000 Meters
Place of Origin
Hebei, China
Brand Name
New baofeng
Model Number
fire resistance halgen free low smoke control cable, PVC shieled flexi
Insulation Material
PVC
Type
Low Voltage
Application
Construction
Conductor Material
Copper
Jacket
PVC
Specifications
fire resistance halgen free low smoke control cable, PVC shieled flexible control cable1.CE,ISO,CCC,PCCC certificate
fire resistance halgen free low smoke control cable, PVC shieled flexible control cable
1. Standard
The control cable can be produced according to the standard GB9330-1988, and the factory can also manufacture the cables in accordance with other standards.
2. Scope of Application
The control cable are suitable for the wiring of electrical controlling equipments and instruments, monitoring and controlling return circuit, electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.
3. Service Conditions
(1)The long-time working temperature of conductor of PVC insulated control cable is 70°C
The long-time working temperature of conductor of XLPE insulated control cable is 90°C
(2) The temperature for laying the cables can not be lower than 0°C. Permissible bending radius(r): Unarmoured cable: R≥ 6D; (D: Outer diameter of the cable); Armoured or copper-tape screened cable: R≥ 12D; Shielded flexible cable: R≥ 6D
Control Cable
| Type | Name | Section Area(mm2) | No. of Core | Application Site |
| KVV | Copper Conductor,PVC Insulated and Sheathed Control Cable | 0.75 1.0 1.5 2.5 | 2-16 | Permanent installation indoors,in cable ditches or pipes |
| 4 6 | 2-14 | |||
| 10 | 2-10 | |||
| KVVP | Copper Conductor,PVC Insulated and Sheathed,Braiding Shielded Control Cable | 0.75 1.0 1.5 2.5 | 2-61 | Permanent installation indoors,in cable ditches or pipes where shielding is required |
| 4 6 | 2-14 | |||
| 10 | 2-10 | |||
| KVVP2 | Copper Conductor,PVC Insulated and Sheathed,Copper-tape Screened Control Cable | 0.75 1.0 1.5 2.5 | 4-10 | Permanent installation indoors,in cable ditches or pipes where shielding is required |
| 4 6 | 7-61 | |||
| 10 | 4-10 | |||
| KVV22 | Copper Conductor,PVC Insulated and Sheathed,Steel tape Armored Control Cable | 0.75 1.0 1.5 2.5 | 7-61 | Permanent installation indoors,in cable ditches,Be able to withstand stronger external mechanical force |
| 4 6 | 4-14 | |||
| 10 | 4-14 | |||
| KVVR | Copper Conductor,PVC Insulated and Sheathed,Flexible Control Cable | 0.5-2.5 | 4-61 | Installation indoors where flexibility and movability are required |
| KVVRP | Copper Conductor,PVC Insulated and Sheathed,Braiding shielded Flexible Control Cable | 0.5 0.75 1.0 | 4-61 | Installation indoors where flexibility shielding and movability are required |
