Specifications
Clip on Guinean generator for 40feet reefer container1.Isuzu engine
2.Vigor alternaotor
3.smartgen auto start module
4.1ye
Clip on Guinean generator for 40feet reefer container
Manufactured by Zhejiang Universal Machinery Co.,Ltd
Genset Model |
30ESX |
||
SET |
Rated power(Kw/kva) |
24/30 |
|
Frequency(Hz) |
60 |
||
Pahse |
3 |
||
Voltage(V) |
460 |
||
Current(A) |
37 |
||
Fuel capacity(L) |
82 |
||
|
Fuel consumption(L/Hour)
|
5.0 |
||
Dimension (mm) |
L |
2300 |
|
W |
850 |
||
H |
1100 |
||
Weight(kg) |
770 |
||
Noice level for silent type (Db/7m) |
65 |
||
ENGINE |
Model |
4JB1 |
|
Prime power(kw/kva) |
24/30 |
||
Cylinders |
4 |
||
Bore×stroke(mm) |
93×102 |
||
Intake Method |
Natural intake |
||
Displacement(L) |
2.771 |
||
Speed governing |
Mechanical governor |
||
Cooling starting method |
Water cooling |
||
ALTERNATOR |
Model |
DG184F |
|
Rated power(kw/kva) |
22/27.5 |
||
Insulation class |
H |
||
Alternator enclosure |
IP23 |
||
THIS SET COULD BE OPERATED ON 100% OF THE POWER CAPACITY AT ALTITUTE OF 1500M, AMBIENT TEMPERATUR OF 50°C. WE RESERVE THE RIGHT TO EXPLAIN THE TERMS OF THIS SPECIFICATION. | |||
Certificate: SGS,CE,ISO and Soncap,GOST-R ,more options offer
Want more detailed specification or pictures for our mute diesel genset, please contact us
