Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Reefer Chamber Generator
Reefer Chamber Generator
US$ 4,500 - 5,400
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
UNIV
Model Number:
UDW30E
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
25kva Super Silent Generator for MyanmarUS$ 6,000 - 6,600MOQ: 1 Set -
25kva Super Silent Generator for MyanmarUS$ 5,300 - 5,500MOQ: 1 Set
-
30kva UK Reefer Container GensetUS$ 15,000 - 18,000MOQ: 1 Unit
-
UW24E Reefer Container GeneratorUS$ 4,200 - 5,200MOQ: 2 Sets
-
30kva Carrier Type Reefer (Clip on ) Container Diesel Generator GensetUS$ 4,500 - 6,500MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
UNIV
Model Number
UDW30E
Output Type
AC Three Phase
Speed
1500RPM/1800RPM
Frequency
50Hz/60Hz
Rated Power
30kw
Rated Voltage
220/380V
Rated Current
54A
| Model | UDW30E | ||
| Rated output (KW/KVA) | 30/37.5 | ||
| Rated voltage (V) | 400/230 | ||
| Rated current(A) | 54.1 | ||
| Rated frequency | 50Hz | ||
| Power factor | 0.8lagging | ||
| Noise level dB(a) | 76/1m | ||
| Excitation | Brushless self-excitation | ||
| Phase Number and connection | 3-phase 4-wire system | ||
| Diesel Engine | R4100ZD1 ,Water cooled type,Turbo Charge Made by UNIVpower |
||
| Alternator model | STAMFORD | ||
| Rated Power (kw/1500rpm) | 42 | ||
| Fuel consumption (g/kw*h) | ≤225 | ||
| Cylinder number | 4 | ||
| Displacement ( L) | 3.61 | ||
| Cooling system | Water cooling | ||
| Environmental Conditions | Altitude≤1000M, Cooling air temperature -15°C~ 40°C, Relative humidity≤90% |
||
| Start Method | 12V Electric start | ||
| Dimension of set (mm) |
L | 2400 | |
| W | 1000 | ||
| H | 1500 | ||
| Net weight of set (kg) | 850 | ||
| Other spare parts (1 piece) | Gallus Air filter element Diesel oil filter element Machinery oil Specification Special tool |
||
package
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2007
Factory Size
10,000-30,000 square meters
Total Employees
101 - 200 People
