Specifications
ISO9001&CE Certificate27 Years' Trusted Plant
Lifetime Service
Polyurethane Spraying Foam Machine
We are the largest and most experienced machinery trusted manufacturer in China .
With powerful R&D team,we have been in PU/Polyurethane Continuous Insulated Panel Production Line since 1987. More Details, CONTACT NOW !
Mob:0086-13832148917 , skyp: hbgxmachinery07 , wechat: s2729355624
Automatic Continuous Polyurethane Spraying Foam Insulation Machine
PU Foaming Machine Introduction:
1.This machine is used for continuous foaming for 2-15cm thickness panel, for example:PU insulation panel,PU sandwich panel.
2.The main components of the machine are imported original components,overall appearance, compact structure,easy maintenance,modular design approach.Our professional designers can meet any of your requirements.
3.The machin based on polyether polyol and polyisocyanate in the blowing agent, catalyst, emulsifiers and a variety of chemical additives present, after the foaming reaction and obtain foam.
PU Foaming Machine Technical Parameter:
| Output | Mdi:240-1200kg/g |
| Polyol:200-1000kg/h | |
| Working Pressure | 100-150bar |
| Power | 60KW |
| Power Supply | 3*380V/50HZ |
| Control Voltage | AC220V/24V |
Componets of the machine:
1.Storage Components:
Double insulation stainless steel tanks.
Electrical resistance heater and cooling water solenoid valves for temperature conditioning
Chiller for option
2.Metering Unit
High precision axial piston pump,Variable output, robust manual adjustment via handwheel with integral precision measuring scale
Magnetic coupling ensures no material leakage
Digital pressure gauge for controlling pressure
3.Mixing Head
Auniform foam mixture distribution on the continuously moving facing
High pressure impingement style mixing,
Self-cleaning design
4.Electrical control system
Electric wiring and connections for each equipment part of the high pressure foam dispensing machine.
Electric control cabinet complete with electric power part
PLC,electric controls and devices for high pressure foaming machine
Alarm function with acoustic warning.
PU Foaming Machine Working Process Draft:
Application of the machine:
Appearance of the PU Foaming Machine :
In wooden case, plastic paper or wrapped with film, etc.
Within 30-35 days after receiving advance payment or L/C.
Professional R&D Team:
Specializes in desiging,manufacturing and supplying custom engineered.
Our designers can meet any of your requirements.
Professional after-sale service.
1 Year warranty.
Lifetime Technical Service.
114th,115th Canton Fair.
Certification
Glimpse of the Plant
1 Equipment should be kept clean and tidy countertops.
2 Strengthen the machinery and equipment maintenance work .
If you interest our machine , pls contact us for more details :
Mob:0086-13832148917 , skyp: hbgxmachinery07 , wechat: s2729355624
