Help Center60mm Fiber Optic Protection Sleeve
Related Products
-
50mm Fiber Optic Protection SleeveUS$ 0.018 - 0.032MOQ: 1 Piece -
45mm Fiber Optic Protection SleeveUS$ 0.018 - 0.032MOQ: 1 Piece
-
40mm Fiber Optic Protection SleeveUS$ 0.018 - 0.032MOQ: 1 Piece
-
Fiber Optic Protection SleeveUS$ 0.028 - 0.046MOQ: 1 Piece
-
TWFSTK-B Fiber Optic Tool KitsUS$ 342 - 572MOQ: 1 Piece
Specifications
Fiber Optic Protection SleeveCrosslinked polylefin
Easy for application
Different sizes and colors available
ROHS and SGS
60mm Single Fiber Protection Sleeve Characteristics:
- Single holed (pre-shrunk)
- Clear sleeve design
- Smooth stainless steel reinforcing member
- Sealing structure suitable to temperature
- Extended liner length
- Low shrink temperature
- Pre installed stainless steel or ceramic rod
- Accommodates single or ribbon fibers
- Wide range of sizes
- Operating temperature -45degree to 100degree
- Min. full recovery temp: 120degree
60mm Single Fiber Protection Sleeve Application:
- Fusion splicing Fiber cable protecting
60mm Single Fiber Protection Sleeve Brief Introduction
60mm Single Fiber Protection Sleeve is applied to the optical fiber closure to fix and protect the optical fiber when splicing. The 40mm Single Fiber Protection Sleeve can be divided into two types (single 60mm Single Fiber Protection Sleeve and ribbon 60mm Single Fiber Protection Sleeve) according to the function.
The single type is used for the single-fiber, and the mass type is used for the ribbon fiber. It is different in the reinforcement between two types. The single one realizes the reinforcement by the stainless steel needles, the later one via the ceramic reinforcement member to realize the function. Ribbon 60mm Single Fiber Protection Sleeve means there are several cores for the fiber. So the mass 60mm Single Fiber Protection Sleeve includes 4cores, 6cores, 8cores, 12 cores (for types).
60mm Single Fiber Protection Sleeve Pictures:
-
60mm Single Fiber Protection Sleeve
-
60mm Single Fiber Protection Sleeve
60mm Single Fiber Protection Sleeve Parameters:
Size |
Splice protector(mm) |
Fusion tube(mm) |
Steel rod(mm) |
Packing |
|||
O.D |
L |
I.D |
L |
O.D |
L |
(pcs/bag) |
|
Large sleeves | |||||||
TWSP-61 |
3 |
61 |
1.4 |
61 |
1.5 |
55 |
100 |
TWSP-45 |
3 |
45 |
1.4 |
45 |
1.5 |
40 |
100 |
TWSP-23 |
3 |
23 |
1.4 |
23 |
1.5 |
18 |
100 |
Standard sleeves | |||||||
TWSP-61T |
2.5 |
61 |
1.4 |
61 |
1 |
57 |
100 |
TWSP-45T |
2.5 |
45 |
1.4 |
45 |
1 |
41 |
100 |
TWSP-40T |
2.5 |
40 |
1.4 |
40 |
1 |
36 |
100 |
TWSP-30T |
2.5 |
2.5 |
1.4 |
30 |
1 |
36 |
100 |
TWSP-25T |
2.5 |
2.5 |
1.4 |
25 |
1 |
21 |
100 |
Mini/micro sleeves | |||||||
TWSP-40M |
1.3 |
1.3 |
0.35 |
40 |
0.5 |
40 |
100 |
TWSP-25M |
1.3 |
1.3 |
0.35 |
25 |
0.5 |
25 |
100 |
TWSP-18M |
1.3 |
1.3 |
0.35 |
18 |
0.5 |
18 |
100 |
TWSP-15M |
1.3 |
1.3 |
0.35 |
15 |
0.5 |
15 |
100 |
TWSP-10M |
1.3 |
1.3 |
0.35 |
10 |
0.5 |
10 |
100 |
