BFC8120 floodlight tunnel lamp ex proof lights

   BFC8120  ex proof lights floodlight tunnel lamp

1. Can be used in hazardous areas: Zone 1 and Zone 2 .

2. Can be used in explosive gas atmospheres of Category II A and II B where the temperature classification is T1-T6.

3. Hazardous zone : 20. 21. and 22

4. Flammable dust atmosphere.

5. Widely used in the fields of oil, chemical industry , spaceflight ,war industry and so on.

6.The case is casted of aluminum alloy.

7.Ballat,ignator and lamps integrated.

8.seal gasket is made of heat resistant and anti-aging silicone rubber,with good features of water and dust proof.

APPLICATION:

• Pieces suitable for explosive gas environment 1zone and 2 zone.
• Pieces suitabel for IIA IIB IIC explosive gas environment
• This product in hazardous: zone20 zone21 zone22
• Should apply to the temperature group for T1-T4(T6) environment
• Designed for petroleum exploitation, refinery,storage,chemistry,medicine military and military facilities etc. sites with potential explosive atmosphere.

TECHNICAL PARAMETERS:

• Meet a criterion:GB3836.1 GB3836.2 GB3836.3 GB12476.1 IEC60079-0 IEC60079-1 IEC60079-7 EN60079-0 EN60079-7
• Explosion proof mark:Exd II BT4 Gb DIP A21 TA T4
• Rated voltage:AC220V
• Lamp power:N70 N100 N110 L35 L70 N100 N150 G80 G125
• Emergency power:L70
• Charging time:24H
• Discharge time:90MIN
• Protection grade:IP65 IP66
• Explosion proof grade:WF1 WF2
• Inlet thread:G3/4"
• Cable outer dia:9mm-14mm

FEATURES:

• The case is die-casted of aluminum alloy ,surface plastic-sprayed on high pressure electrostatic technique. Stainless steel fasters.
• High impact resistance tempered glass cover,with anti-dazzle design.
• Seal gasket is made of heat resistant and anti-aging silicone rubber,with good futures of water and dust proof.
• Ballast ,ignator and lamps integrated.
• Cable connection or pipe cabling.
