I. Main features of roof ridge cap roll forming machine:
Our roof ridge cap roll forming machine can form metal ridge which is mostly used with colorful roofing tile sheets. After roll formed by this machine, the surface will be smooth and beautiful without any scratch on surface.
The roof ridge cap is widely used in many kinds of industrial factory, civilian buildings, and wall board for attached part product. It has advantage of pretty appearance, durable using and so on. It is producted continuously as roll forming machine instead using bending machine to make angle tile saving human resources, lower labor cost.
II. Technological process:
Uncoiling—Feeding—Leveling—Punching—Roll forming—Cutting—Products
III. Main technical specifications of roof ridge cap roll forming machine:
Steel thickness: 0.4-0.8 mm
Forming speed: 3-6 m/min
Roller stands: 16 stand
Roller material: 45# steel, coated with chrome
Main motor power: 7.5 kw
Hydraulic cutting power: 4 kw
Hydraulic pressure: 10-12 Mpa
Power supply: 380V,50HZ, 3 phase
Tolerance: 1.5 mm
Material of cutting: Cr12
Control system: PLC with touch screen
Machine net weight: 8 T
