Help Center20mm 5 Axis Cnc Compression Spring Machine
Related Products
-
China 0.1mm Automatic Compression Spring MachineNegotiableMOQ: 1 Set -
GJ-20A Cnc Spring Washer Making MachineNegotiableMOQ: 1 Set
-
GJ-20A 4 Axis Conical Spring MachineNegotiableMOQ: 1 Set
-
GJ-200A Dongguan Big Diameter Cnc Compression Spring MachineUS$ 220,000 - 230,000MOQ: 1 Set
-
GJ-80A 8mm 5 Axis Cnc Compression Spring MachineNegotiableMOQ: 1 Set
Features of GJ-200 compression spring machine
1, The hardware system highly integrated,so that failure rate is reduced to a minimum and the stability is improving greatly.
2, Don’t need to stop the machine can use hand- shaking wheel at anytime to change the speed of the machine
3, Simple repetitive programming cooperates with the probe speed can be set for producing flat springs etc., manifold cycles
4, ensure that the 100% Taiwan imported, superior quality
Sample
Technical Parameters
Model |
GJ-200A compression spriing machine |
Axis Count |
5 axis |
Wire Size Range |
Φ10mm~φ20mm |
Max Feeding Length |
Unlimited |
Wind direction |
Right and Left Hand |
Max Feeding Speed |
30m/min |
Min Setting Value |
0.01mm |
Max Setting Value |
9999.99mm |
Outside Diameter |
≤280.00mm |
Cam Min Seting Value |
0.1° |
Cam Max Setting Value |
359.9° |
Wire Feed Servo Motor |
55kw |
Cutter servo motor |
22kw |
Pitch Servo motor |
5.5kw |
Cam Motor |
22kw |
Wood Box Size |
3190*2280*2850 mm |
Electric Box Size |
1400*880*2100 mm |
Weight |
32500kg |
Our Advantage
1, 12 years' experience in this area
2, Experienced employee and international famous components make the machine high stable and accuracy.
3, We research and develop new machines or modify machines according to clients' products.
4, Get trusted by famous company, Midea, TK, etc. And, our machines art exported to more than 10 countries.
Service
1, Making samples for free after getting your order
2, 1 year warranty
3, Free training to your engineer
4, Lifetime maintenance
Place order to us
Packaging
The spring machine are packed in a very fir wood case, and the machines are protected by plastic film inside.
Company profile
Dongguan city guang jin CNC equipment co., LTD Is engaged in the computer spring machine, compression spring machine, professional production, research and development, design, sales, service as one of the famous high-tech enterprises in guangdong province, product marketing in Europe and southeast Asia and other countries and regions,deeply domestic and foreign customers favor!"Guang jin" can be the development and manufacture according to customer's personalized needs of different specifications of the models.
