Jiangyin Weiping Machinery Co., Ltd.: Wuxi, Jiangsu, China; Main products: pulverizer, mixer, granulator machine, sifter, mixing machine

Home > Products > Screener,Sifting Machine,Sifter Machine > Chemicals Machine Electric Sifter ZS Series Screening Machine

Chemicals Machine Electric Sifter ZS Series Screening Machine

FOB Price

USD $2000.00 - $2000.00 / Set

1 Set(Min.Order)

Supply Ability 20 Set / Sets per Month
Port shanghai port for Chemicals Machine Electric Sifter ZS Series Screening Machine
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Product Type	Other, no	Place of Origin	Jiangsu, China
Brand Name	WP	Model Number	ZS-0.8㎡
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

1.Product name:Chemicals Machine Electric Sifter ZS Series Screening Machine

Product Description

2.Main Application :

The machine is suitable for industries such as pharmacy,chemical,foostuff,fodder,construction,etc,serving as ideal equipment for sifting and grading of granules and powder.

3.Working Method :

The machine is composed of box,vibration source and anti-vibration damp.The vibration frame is connected with the sieve box with 4.12units of soft rubber to fix the anti-vibration damp so as to produce centrifugal force.The vibration swing is controlled by the anti-vibration damp to sift materials.The machine is suitable for the sifting of materials which contain much fiber,high viscosity and humidity.

4.Technical Data :

Model	0.5	0.8m²	1.2m²	1.8m²	2.0m²
Capacity(kg/h)	80-850	100-1100	120-1200	160-1600	200-2000
Number of mesh(Mesh)	3-120	3-120	3-120	3-120	3-120
Motor power (kw)	0.4	0.5	0.75	1.1	1.5
Vibration frequency(r/min)	1400	1400	1400	1400	1400
Vibrating ratio(kn)	0-2.5	0-2.5	0-2.5	0-2.5	0-2.5
Weight(kg)	280	420	520	680	800
Overall size(L×W×H)	1450×600×1050	1880×850×1350	2200×100×1450	2400×1200×1500	2800×1200×1600

Detailed Images

Packaging & Shipping

wooden packing

Our Services

one year guarantee for whole machine

24 hours technical support by email

calling or door-to-door service

user manual and detailed video/CD
