1.Product name: ZS Series High Efficient Vibrating sieve
2.Main Application:
The machine is applied for the sorting of the granule size of dry power material market in the trades medicine,chemical and foodstuff etc.And it can sift out the product continuously.
3.Structure Characteristics:
The machine is composed of the vertical vibration motor a sieve bottom a mesh frame sieve room rubber vibrating bowl and all fastening pieces,etc.It can be operated for the sorting purpose either in single sieve or multi-sieves with a compact structure easy operating and repairing,smooth running,low noise,large target material treatment good fineness and wide applicability,etc.
4.Technical Data:
Model |
400 |
600 |
800 |
1000 |
1200 |
|
Capacity(kg/h) |
100-800 |
200-1500 |
300-2500 |
50-3500 |
800-5000 |
|
Number of mesh(Mesh) |
2-200 |
2-200 |
2-200 |
2-200 |
2-200 |
|
Vibration frequency(r/min) |
1500 |
1500 |
1500 |
1500 |
1500 |
|
Motor power(kw) |
0.2 |
0.4 |
0.75 |
1.1 |
1.5 |
|
Weight(kg) |
200 |
250 |
320 |
420 |
600 |
Overall size(mm) |
650×500×1100 |
860×650×900 |
1100×850×950 |
1350×1100×1100 |
1600×1250×1100 |
wooden packing
one year guarantee for whole machine
24 hours technical support by email
calling or door-to-door service
user manual and detailed video/CD
