Help CenterSports Stadium Perimeter Led Display Screen Sign
Related Products
-
Video Play Pixel Pitch 10MM Outdoor LED Display Stadium Billboard Advertising BusinessUS$ 800 - 1,288MOQ: 1 Square Meter -
Sports Stadium Perimeter Led Screen CurtainUS$ 800 - 1,288MOQ: 1 Square Meter
-
Stadium Led tv ScreenUS$ 800 - 1,288MOQ: 1 Square Meter
-
Outdoor Led Displays 10mm Electronic Led Signs for Outdoor Digital AdvertisingUS$ 400 - 1,288MOQ: 1 Square Meter
-
Led Sports Stadium Perimeter Screen PanelUS$ 800 - 1,288MOQ: 1 Square Meter
Specifications
1.PH20mm full color outdoor large stadium led display screen2.Big viewing angle
3.High brightness
4. 2 years
sports stadium perimeter led display screen sign
Quick Details
1. P20 full color outdoor led display module size:320mm*160mm
2. Brightness:6500cd/sqm
3. Pixel density:2500dots/sqm
4. Average Power:185w/sqm
5. IP rate: IP67 full waterproof
6. Design life:100000hours
Feature and Advantage
1. Brightness: >5000 cd/m2. the pixel can be adjusted point by point to reach the white balance.
2. Special design, the screen can be curved to any shape.
3. Without steel frame, the screen is very light, it is good for building body. only using a hanging bar, it can be installed easily and fast
4. High refresh rate: 4000 Hz. It is suitable for high-end video camera 5. With strip moudel, it is more transparent.
Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win
6. Export countries : Peru, Mexico, Colombia, Turkey, US, UK, etc.
Trade Terms
1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm led football stadium display p20 outdoor full color
5.Delivery time: 10 days after receive pre-payment
p20 full color outdoor led display Parameter
| Specification | Flexible curtain | ||||
| LED Lights | SMD 5050 3 in 1 | ||||
| Pixel Pitch | 20 mm | ||||
| Pixel Resolution | 2500 dots | ||||
| Pixel Composing | 1R1G1B | ||||
| Module Dimension(W*H) | 15mm*320mm*1280mm | ||||
| Single module Weight | 4.10kg | ||||
| Viewing Range | 20m to 66m | ||||
| Horizontal Viewing Angle | 135° | ||||
| Vertical Viewing Angle | 100°~120° | ||||
| Maximum Power Consumption | 210W/PCS ,513 | ||||
| Graphic card | DVI | ||||
| Control Method | synchronization | ||||
| LED Driver | constant current | ||||
| Scan mode | Static | ||||
| Frame Changing Frequency | ≥60Hz | ||||
| Refresh Rate | ≥1000Hz | ||||
| Brightness | ≥5000cd | ||||
| Ingress Protection (Front/Rear) | IP66 | ||||
| Operation Temperature | (-40°C~50°C) | ||||
| Operation Humidity | 10%~95% | ||||
| Input Voltage | AC220V/110V±15% 47-64Hz | ||||
| Gray Scale | 4096 | ||||
| Brightness Adjustment | 256 level | ||||
| System Operating Platform | WINXP,WIN2000,WIN98 etc | ||||
| Support Mode | DVI,VGA,S-Video,RGBHV,COMPOSITION etc | ||||
| Control System | DVI graphic card+control card(gigabyte)+optical fibre transmission(option) | ||||
| NTBF | ≥50000 hours | ||||
| Life Time | 100000 hours | ||||
LED display certificates
Working factory:
Applications:
