Specifications
1football score video panel P10 DIP stadium led display2.Big viewing angle
3.High brightness
football score video panel P10 DIP stadium led display
Quick Details
1. P12 football stadium hd video led display
2. Brightness:7000cd/sqm
3. Pixel density:6944dots/sqm
4. Average Power:185w/sqm
5. IP rate: IP67 full waterproof
6. Design life:100000hours
Feature and Advantage
1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system
2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system
3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof your LED display screen's investment.
4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win
6. Export countries : Peru, Mexico, Colombia, Turkey, US, UK, etc.
Trade Terms
1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm p10 outdoor led display
5.Delivery time: 10 days after receive pre-payment
LED Screen Parameter
| Items | P12 Led display |
| Pitch size | 12mm |
| Module size | 192mm*192mm |
| Panel pixel(dots) | 16*16 |
| Pixel configuration | 1Red,1Green,1Blue |
| Color scale | 65536degree/16777216colors |
| Pixel density | 6944pixels/square meter |
| View angle(H/V) | 120/60degree |
| Brightness | ≥6500nits |
| View distance | 15--200m |
| Power consumption | 100-1200W/square meter |
| Net weight | less than 65kg/square meter |
| Operating temperature | —25°C~+60°C |
| Operating humidity | 10%—95%RH |
| Life time | ≥100,000hours |
| Exchange frame speed | >150frames per second |
| Refresh frame frequency | 600Hz |
| Control distance | 120m (without relay),single mode fiber: 20000m,multi mode fiber:500m-20km |
| Power | 110V/220V/380V±15% 50Hz |
| operating system | Windows98/Me/2000/Xp |
| Drive mode | constant current driving |
| display mode | VGA640X480—VGA1600X1024 |
| Input Voltage | AC220v/50Herts |
| Protections for outdoor display | IP65 |
| Accepting signal | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
High quality LED lamps material
High quality led connectors & LED Control system diagram
LED display certificates
Working factory:
Applications:
