Single color P10 outdoor led display

Specifications

1.Single color P10 outdoor led display
2.size:320mm*160mm
3.Weight:0.4kg
4.2 years warranty
5.CE,ROHS

Single color P10 outdoor led display

Quick Details



1. P10 waterproof single Red color led display screen size:320mm*160mm

2. Brightness:2500cd/sqm

3. Pixel density:10000dots/sqm

4. Average Power:100w/sqm

5. IP rate: IP67 full waterproof

6. Design life:100000hours



Introduction



Energy saving led display is famous for low consumption. This is the trend for future advertising. Compared with traditional printed advertising, energy saving led display is outstanding for lower unit cost, environment friendly and vivid presentation.
Especially new IC card, MBI 5035 can save 50% power supply with longer lifespan and excellent cooling. There is a great money reduction for large size led display advertising.
With the realization of green environment, People pay more and more attention to ways of reducing power consumption.





Feature and Advantage



1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system

2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system

3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof  your LED display screen's investment.

4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.

5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.



Our service





1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.



Trade Terms



1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:1sqm

5.Delivery time: 15days after receive pre-payment



LED Screen Parameter



Description	Technical parameter
Unit module	Module size	320*160mm
	Pixel pitch	10mm
	Pixel density	10000dots/sqm
	Pixel configuration	1R
	Led specification	Φ5ellipse
	Pixel resolution	W:32dots*H:16dots
Cabinet	Dimension	960mm*960mm*120mm
	Quantities of module	18pcs
	Power supply	2pcs
	Thermal discharge	Fan*2pcs
	Total weight	65kg
	Best viewing distance	10-100m
	Temperature	Storage: -35°C~+85°C
		Working: -35°C~+85°C
	Thickness	15cm can adjustable
	Remarks: cabinet size can changed, upon project need.
Power	Working voltage	AC220V/110V±10%
	Average power consumption	≤185W
	Max. Power consumption	≤600W/sqm
	Current	≤20mA(single LED)
Control system	CPU	Pentium4 or above
	Operating system	WIN98/2000/NT/XP
	Control method	Synchronization
Main technical parameter	Driving device	Static constant current
	Drive type	Constant Current driver IC
	Refresh frequency	≥400Hz
	Grey scale/colors	256 levels of each color(R/G/B)/16.7M color
	Brightness of white balance	More than 7500cd/sqm
	Brightness adjustment	256 levels of each color(R/G/B)by software
	Operating ambient humidity	10%--95%
	Video signal	PAL/NTSC
	Control system	DVI display card+full color controller card
	MTBF	≥10,000hours
	Life span	≥100,000hours
	Flatness	Tolerance of interpixel ≤0.3mm
		Tolerance of modules clearance≤0.6mm
	Power switch	Automatic switch
	Display mode	1024*768
Software	LED media player



High quality LED lamps material











High quality led connectors











LED Control system diagram



LED display certificates
