direct factory P4 indoor stage background RGB rental led screen

Specifications

1.direct factory P4 indoor stage background RGB rental led screen
2.Big viewing angle
3.High brightness
4.2 years warranty

direct factory P4 indoor stage background RGB rental led screen

Quick Details



1.  2013 Housing Fair use p4 indoor led display module size:128mm*128mm

2. Brightness:1500cd/sqm

3. Pixel density:62500dots/sqm

4. Average Power:185w/sqm

5. IP rate: IP43

6. Design life:100000hours



Feature and Advantage



1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our JC LED display screen system

2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system

3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof  your LED display screen's investment.

4.Long-term Brightness:More 7000-nit brightness(for outdoor full color led display)(2000 nits brightness for indoor full color led display)capacity throughout product lifetime of the LED display screen.

5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.



Our service



1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.



Trade Terms



1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:1sqm  p4 indoor full color led display.

5.Delivery time: 10-15days after receive pre-payment



2013 Housing Fair use p4 indoor led display Parameter



Description	Technical parameter
Unit module	Module size	128*128mm
	Pixel pitch	4mm
	Pixel density	62500dots/sqm
	Pixel configuration	1R1G1B
	Led specification	smd2121
	Pixel resolution	W64:dots*H:32dots
Cabinet	Dimension	512mm*512mm*90mm
	Quantities of module	16pcs
	Power supply	3pcs
	Thermal discharge	Fan*2pcs
	Total weight	10kg
	Best viewing distance	4-150m
	Temperature	Storage: -35°C~+85°C
		Working: -35°C~+85°C
	Thickness	12cm can adjustable
	Remarks: cabinet size can changed, upon project need.
Power	Working voltage	AC220V/110V±10%
	Average power consumption	300-400W
	Max. Power consumption	≤1000W/sqm
	Current	≤20mA(single LED)
Control system	CPU	Pentium4 or above
	Operating system	WIN98/2000/NT/XP
	Control method	Synchronization
Main technical parameter	Driving device	1/16scanning
	Drive type	Constant Current driver IC
	Refresh frequency	≥400Hz
	Grey scale/colors	256 levels of each color(R/G/B)/16.7M color
	Brightness of white balance	More than 8000cd/sqm
	Brightness adjustment	256 levels of each color(R/G/B)by software
	Operating ambient humidity	10%--95%
	Video signal	PAL/NTSC
	Control system	DVI display card+full color controller card
	MTBF	≥10,000hours
	Life span	≥100,000hours
	Flatness	Tolerance of interpixel ≤0.3mm
		Tolerance of modules clearance≤0.6mm
	Power switch	Automatic switch
	Display mode	1024*768
Software	LED media player



High quality LED lamps material











High quality led connectors













LED Control system diagram



LED display certificates









2013 Housing Fair use p4 indoor led display working factory:







Applications:









  p4 indoor full color led display aging





  p4 indoor full color led display case
