Home > Consumer Electronics > LED Display > Indoor LED Display > Indoor Full Color hd Super Slim Die Casting P3 Led Rental Led Display / Video Wall / Board

Indoor Full Color hd Super Slim Die Casting P3 Led Rental Led Display / Video Wall / Board

Indoor Full Color hd Super Slim Die Casting P3 Led Rental Led Display / Video Wall / Board photo-1

Indoor Full Color hd Super Slim Die Casting P3 Led Rental Led Display / Video Wall / Board photo-2

US$ 3,765 - 4,058 MOQ: 1 Square Meter

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

JC-FSI-PH3MM

Contact Supplier Request Quote Chat Now

Shenzhen Jingcan Opto-Tec Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name JC

Model Number JC-FSI-PH3MM

Usage Indoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, Hot sale HD indoor full color rental led display

Screen Dimension 576mmx576mm

indoor full color hd super slim die casting P3 led rental led display / video wall / board

Quick Details:

1, Full black LED Chips;

2, Sum sery LED driver IC;

3, LED Source: SMD2121

4, LED Module Size: 240mm x 240mm;

5, LED Cabinet Size: 480mm x 480mm x 65cm;

6, Contrast Ratio: 4000:1;

Product Description

1, 4000:1 high contrast ratio ensure a vivid and real and natural color display;

2, Stable quality: extrusion aluminum LED display is of high quality for frequent movement from one site to next;

3, Ultra light weight: Utilizing extrusion aluminum LED cabinets;

4, Ultra slim: Rental LED display is designed at 65mm thickness;

5, Easy handling: With ultra light weight and fast lockers features, the LED cabinet can be easily assembled and dismantled by one single person;

6, Full black LED chips together with high refresh frequency,high grey grade features makes P3 indoor rental LED screens color is soft for people's eye, comfortable to watch.

Specification

LED MODULE PARAMETER
Pixel pitch (mm)	3
Pixel configuration	3 in 1
Encapsulation	SMD2121
Colors matches	6:3:1
Module resolution (pixels)	80 x 80
Module pixel	6400
Module size (mm)	240 x 240
LED CABINET SPECIFICATION
Cabinet size (mm)	480 x 480 x 65
Cabinet resolution (pixels)	160 x 160
Cabinet pixels (pixels)	25600
Cabinet material	Extrusion Aluminum
Cabinet weight (kg)	6.5kg
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2)	111111
Brightness(cd/m2)	≥1500 (adjustable)
Brightness adjusted	100 grade by software or by Auto-optic induced
View angle	Horizontal 140°; Vertical 140°
Best viewing distance (m)	≥2.5m
Communication distance(m)	<100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m; Single mode fiber cable < 20km
Display work method	1/16 Scan
LED driving method	Constant driving current
Color contrast ratio	4000:1
Gray Grade	16bit
Display Color	439, 804, 651, 110
Refresh Frequency (Hz)	≥1000
Picture display method	Intellective control technology , test-itself technology , correct technology, Synchronization Control
Input signal	DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting )
System operating	WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level	IP43
Working temperature(ºC)	-20~+60
Stored temperature (ºC)	-30~+80
Operation humidity(RH)	0-95%
Display Lifetime(hours)	10 years or more( natural environment) 100000 hours( ideal environment)
Maintenance	Rear side
Working Voltage	AC110 / AC220V±10% 47~63HZ
Out of controlled dot	≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one)
