P6 Outdoor SMD3535 Full Color LED Module Display 192x192mm

P6 Outdoor SMD3535 Full Color LED Module Display 192x192mm thumbnail-1
P6 Outdoor SMD3535 Full Color LED Module Display 192x192mm thumbnail-2
P6 Outdoor SMD3535 Full Color LED Module Display 192x192mm photo-1
P6 Outdoor SMD3535 Full Color LED Module Display 192x192mm photo-2
US$ 1,088 - 1,258 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JC
Model Number:
JC-FSO-PH6MM
Contact Supplier Request Quote Chat Now
Shenzhen Jingcan Opto-Tec Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name JC
Model Number JC-FSO-PH6MM
Usage Outdoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, P6 Outdoor SMD3535 Full Color LED Module display 192x192mm
Screen Dimension 576mmx576mm

P6 Outdoor SMD3535 Full Color LED Module  display 192x192mm



Quick detalied
  • Pixel pitch: 6 mm
  • Encapsulation: SMD35351024pixel dots
  • Pixel density: 27777 pixel dots/m²
  • Brightness of white: 6,500CD/m² at least
Parameter





Description

Technical parameter

Unit module

Module size

192*96mm

Pixel pitch

6mm

Pixel density

27777dots/sqm

Pixel configuration

1R1G1B

Led specification

SMD2828

Pixel resolution

W32:dots*H:32dots

Cabinet

Dimension

576mm*576mm*80mm

Quantities of module

18pcs

Power supply

3pcs

Thermal discharge

Fan*2pcs

Total weight

12kg

Best viewing distance

6-150m

Temperature

Storage: -35°C~+85°C

Working: -35°C~+85°C

Thickness

12cm can adjustable

Remarks: cabinet size can changed, upon project need.

Power

Working voltage

AC220V/110V±10%

Average power consumption

300-400W

Max. Power consumption

≤1000W/sqm

Current

≤20mA(single LED)

Control system

CPU

Pentium4 or above

Operating system

WIN98/2000/NT/XP

Control method

Synchronization

Main technical parameter

Driving device

1/16scanning

Drive type

Constant Current driver IC

Refresh frequency

≥400Hz

Grey scale/colors

256 levels of each color(R/G/B)/16.7M color

Brightness of white balance

More than 8000cd/sqm

Brightness adjustment

256 levels of each color(R/G/B)by software

Operating ambient humidity

10%--95%

Video signal

PAL/NTSC

Control system

DVI display card+full color controller card

MTBF

≥10,000hours

Life span

≥100,000hours

Flatness

Tolerance of interpixel ≤0.3mm

Tolerance of modules clearance≤0.6mm

Power switch

Automatic switch

Display mode

1024*768

Software

LED media player



Detailed Images

 P6 Outdoor SMD3535 Full Color LED Module display 192x192mmP6 Outdoor SMD3535 Full Color LED Module display 192x192mm

Packaging & Shipping

Usually, there are three tyeps of package design.

Firstly, we pack the LED display in the paper carton.

P6 Outdoor SMD3535 Full Color LED Module display 192x192mm

Secondly, we will pack the LED display in the flight case if  customer request for frequent movement.

P6 Outdoor SMD3535 Full Color LED Module display 192x192mm

Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.

P6 Outdoor SMD3535 Full Color LED Module display 192x192mm
