Specifications
1.Full color video high brightness p12 outdoor red led module2.Big viewing angle
3.High brightness
4.2 years warranty
Full color video high brightness p12 outdoor red led module wall
Feature and Advantage
1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system
2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system
3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof your LED display screen's investment.
4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win
6. Export countries : Peru, Mexico, Colombia, Turkey, US, UK, etc.
Trade Terms
1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm p10 full color outdoor led display screen 5.Delivery time: 10 days after receive pre-payment
LED Screen Parameter
| Numbers | Technical indexes | Specification |
| 1 | Pixel Pitch | 12mm |
| 2 | Density of Pixel | 6944dots/M2 |
| 3 | Pixel configuration | RGB |
| 4 | Size of Single Board | 384mm X 192mm |
| 5 | Colors | 16777216 |
| 6 | Best Viewing Distance | ≥6m |
| 7 | Horizontal Viewing Angle | 140° |
| 8 | Maximum Power Consumption | 300W/m2 |
| 9 | Brightness | 1800nits/m2 |
| 10 | Gray Scale | 14 bits per color |
| 11 | Color Temperature | 6500cd/m2 |
| 12 | Control Method |
synchronization & Asynchronization |
| 13 | Driving method | constant scanning |
| 14 | Frame Frequency | 60Hz |
| 15 | Refresh frequency | ≥480Hz |
| 16 | Working Voltage | AC220V/110±10% |
| 17 | IP grade | IP67 |
| 18 | Working temperature | 10 degree centigrade ∼ +80 degree centigrade |
| 19 | Computer operation system | Win 98/ Win XP/ Win 2000/winme/win7 |
| 20 | Brightness adjustment | 256 grade manual, 8 grade automatic |
| 21 | Video signal | RF, S-Video, RGB, RGBHV, YUV, YC.ect |
| 22 | Software | LED play software |
| 23 | MTBF | More than 10000 hours |
| 24 | Life Span | 100,000 hours |
High quality LED lamps material
High quality led connectors & LED Control system diagram
LED display certificates
Working factory:
Applications:
