PH10mm Waterproof semi-outdoor led display screen
- 2000 Piece / Pieces per Month
- sz
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Guangdong, China | Brand Name: | JC | Model Number: | JC-cabinet-P10 |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Other, Video, Video Display |
Pixels: | 10mm | Screen Dimension: | 160x160mm |
Product Description
Specifications
PH10mm Waterproof semi-outdoor led display screen1.Pixel Configuration:1R, 1G, 1B
2.Pixel Pitch:10mm
3.Video Display
PH10mm Waterproof semi-outdoor led display screen cabinets
1. Advanced digital view frenquency treatment technology
2. Scan by distributed & design with modularization
3. Static drive by constant-current, brighteness adjust willingly
4. Super high brighteness & soled color pixel
5. Vivid menu, no dithering and double image, stop distortion
6. Web control or long-distance control
Item | Technical Specification |
Pixel | Pixel pitch: 10mm |
Pixel configuration: 1R1G1B | |
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd | |
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm | |
Module resolution: 16×16 pixels | |
Module | Module size: 160mmx160mm |
Cabinet size: 800mm×800mm×150mm | |
Cabinet | Cabinet resolution: 6400 pixels |
Cabinet material: Steel | |
Gross weight: 65kg | |
Module quantity: 24 pcs= 4(w) x 6(h) | |
Power consumption : Max.:1000W/m² Everage: 300W/m² | |
Screen parameter | Drive method: static scanning |
Brightness: 7500cd/m² | |
IC driver: MBI 5026 | |
Density: 310000 pixel/m² | |
Whole display flatness: ≤ 1mm juncture | |
Best view distance: ≥ 10m | |
Viewing angle: Horizontal: 120° Vertical: 60° | |
Humidity(RH): ≤ 90~95% | |
Working temperature: from -30°C~ +60°C | |
Working voltage: AC220V/110V±10% | |
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn) | |
Frame rate: ≥ 540Hz | |
Protection grade: IP67 | |
MTBF: More than 10000hrs | |
Life time: 100,000 hrs | |
Control system | Control system: Linsn |
Signal interface: DVI | |
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m | |
Systems operating platforms : XP,WINDOWS(WIN95,WIN98,WIN2000) |
Paper carton for inside led cabinets with foam protection.
Wooden case is available for those2014 led mobile advertising trucks for sale in one case.
Flight case is optional for custoer in case you want to move it easily for those 2014 hot sale p10 outdoor led video wall, same can design two cabinets packed in one flight case or other design available for you.
Aftersales Service Guarantee System
Quality Assurance
After the accomplishment of the LED project, Our company would promise that all equipment warranty for Three years, free charge of maintenance service offered during the warranty period.
Every 3-month regular maintenance service. Our company would provide good service for repairing and only charge the material cost when the warranty time is expired.
Regarding the term of software, our company would offer free updated service for our ordered customer.
7 days and 24 hours whole day of technical support would be provided to our customers in order to make sure that consumers can get help anytime anywhere.
JINGCAN LED FACTORY leads the way in LED display manufacturing & technology. Its advertising LED display, rental use LED display, fixed installation LED display ,stadium perimeter LED display ,mobile trailer LED display , water floating LED display ,transparent LED display ,LED digital billboard, LED mesh display screen for skyscraper's decoration, arc LED panel ,LED components & complete LED full color video systems undergo stringent quality control at ISO 9001-certified manufacturing plants.
JINGCAN LED FACTORY offers user-friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality. Customer satisfaction is our prime objective and our high quality LED video display screen, led screen were used in more than 90 countries and win a high reputation.
JINGCAN LED FACTORY has its own facilities for Marketing, Customer Support, R&D and Manufacturing in China, Europe, USA & Middle East .We have more than 6 years researching & manufacturing experience in this field. Our OEM, ODM mass production mode & 30000.00 Sqm manufacturing base guarantee our high quality economic average cost & fast delivery ability.
Our advanced management regulation, strict quality control system & our experienced, responsible and reliable 700 staff ensure you the best quality, user friendly product and trouble free after sales service.
JINGCAN LED FACTORY helps you concentrate all your time and energy on your main business by the perfect production & service system.
JINGCAN LED FACTORY's strong, experienced & reliable R&D team ensure any kinds of your OEM,ODM cooperation complete in a very fast speed, high quality and strong delivery ability.
JINGCAN LED FACTORY's fast growth need your help, support, wisdom & strength. We are still open for local cooperation with you in your district. If you have interest to be our partner in your local district, please let us know.
