Advertising Stadium LED Display Rental LED Wall for Digital Stadium Scoreboard
Advertising Stadium LED Display Rental LED Wall for Digital Stadium Scoreboard
1, Stable structure: Die casting aluminum LED cabinet
2, Light Weight: Ultra Light Weight at 12.8kg-17.0kg/cabinet
3, Ultra Slim: Ultra Slim LED cabinet at 90cm thickness
4, High refresh frequency up to 2400HZ for stadium LED display use;
5, Hanging up structure for movable rental LED wall use;
6,Movable: Flight Case Package for frequent movement from one site to next
1, This ultra slim rental LED wall is of multi use as stadium LED display and events renatl LED screen use;
2. P10 stadium rental LED wall is of high refresh frequency above 2400HZ to insure flickering free and no water wave images and videos effect during sporting match live broadcast;
3. Stadium LED display is utilizing dual computer control system. During sports LED display use, if one computer turn off due to technical issues,the other one will automatically act as a backup computer to insure stadium LED display working well.
4, High contrast ratio: Stadium LED display is of high contrast ratio at 4000:1 to present true and natural color LED displays;
5, P10 perimeter LED displays is packed into flight case which is convenient movment from one site to next;
6, P10 rental LED screen is of high resolution at 10000pixels/
Perimeter LED Screen
Football Stadium LED Screen
Football Perimeter LED Display
Basketball Stadium LED Displays
Soccer LED Display
Baseball Stadium LED Display Screens
Sporting Stadium LED Video Display
Sports Perimeter LED Screen
Sports Club LED Display
LED Score Boards
LED Score Display
LED Digital Scoreboard
Concerts
TV Studios
Private Parties
Fashion Shows
Product Launches
Press Conferences
Political Gatherings
Programe Live Broadcast
Competitive advantages:
1, Multi Use: P10 rental LED wall can be used as ultra slim rental LED screen for events, it can also be used as scoreboard in stadium;
2, Multi function LED display's both rental LED wall and stadium LED displays structures makes it frequent use in different sporting areas and events site, earning back investment faster;
3, P10 LED display is of high brightness at 8000cd/;
4, Short best view distance,for P10 1RGB outdoor LED scoreboard displays,the best view distance is above 8 meters;
5, The multi function LED display is of rental LED video wall structure like strong hanging pole, fast lockers, hanging bar and bottom pad etc;
6, Flight case package makes multi function LED screens movable from one site to next.
| LED Module Parameter | |
| Pixel pitch (mm) | 10 |
| Pixel configuration | 1R1G1B |
| Encapsulation | DIP346 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 32 x 32 |
| Module pixel | 1024 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 96 x 96 |
| Cabinet pixels (pixels) | 9216 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 55 |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 10000 |
| Brightness(cd/m2) | ≥8000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 110°; Vertical 70° |
| Best viewing distance (m) | ≥8m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m; Single mode fiber cable < 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥2400 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video procrssor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20~+60 |
| Stored temperature (ºC) | -30~+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear |
| Working Voltage | AC110 / AC220V±10% 47~63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Usually, there are three tyeps of package design.
Firstly, we pack the LED display in the paper carton.
Secondly, we will pack the LED display in the flight case if customer request for frequent movement.
Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.

1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
