Best price Energy saving High definition excellent high quality led display P4 indoor full color
Product Features
1.light weight: per square box weighs only 24kg, single box weighs 8KG, single person can
be a single hand, saving installation time;
2.thin box: box with die casting aluminum, high strength, toughness, high precision, easy deformation,
its thickness is only 80mm;
3.Screen Ping: surface flatness error less than 0.2mm, the effective elimination of mosaic;
4.disassembly fast: the box is connected up and down with fast locking mechanism, pull the two handles
90 degrees to lock the two cabinet, 10s to complete a cabinet installation, high mounting accuracy.
Enclosure and wiring connection fast and reliable, that is beautiful in appearance but also to achieve
a real sense of the rapid disassembly;
5.Easy maintenance: modular design, installation and removal easy assembly Screen anywhere, simple to maintain
6.tolerance: a new structure designed to meet the lifting of laminated requirements to meet indoor and outdoor
requirements. Box single, compatible with a variety of pitch, indoor-outdoor module compatibility
7.High gray high refresh rate design,gradation 14 bit,refresh rate above 960Hz
Product Services
1.Your inquiry related to our products or price will be replied in 12hrs.
2.OEM&ODM,any your customized lightings we can help you to design and put into product.
3.Distributoership are offered for your unique design and some our current models.
4.Protection of your sales area,ideas of design and all your private information.
5.Best cost performance and perfect service before and after sales.
Product Applications
P4 Indoor LED Display Screen Applications:
Comercial advertising Indoor LED Display Screen, Stadium perimeter Indoor LED Display Screen, Mobile trailer Indoor LED Display Screen for mobile media,shopping mall Indoor LED Display Screen for logo showing,bank&stock exchange Indoor LED Display board for rates showing, train & bus station Indoor LED Display Screen, air port Indoor LED Display Screen, telecommunication Indoor LED Display Screen system for information showing and instruction.
High resolution, can be used for high-end big screen TV, suitable fro interio home theatre system, compared with conventional TV, it has a larger screen, more bright beautiful color and more shocking display effect. I can be acted as a high-end indoor screens at the same time, used in the various types of indoor places, such as high-end conference rooms, families, halls, cinemas, theatres, lounge, stations and so on.
Product Aging Test
Our led diaplay aging test will have two times,more than 24 hours !
Product Description
| Technical DataModel | PH4 |
| Pixel Pitch | 4mm |
| Physical Density(pixels/m²) | 62500 |
| LED Shape & Size | SMD 3 in 1 |
| LED Arrangement | 1R1G1B |
| Module Size(mm) | 128×128 |
| Module Resolution | 32*32 |
| Drive Mode | Dynamic 1/16Duty Constant Current |
| Brightness | ≥1500cd/m² |
| Contrast(cd/m²) | ≥2000:1 |
| View Angle, 50% Brightness | 160°/160° |
| Minimum View Distance | 4m |
| Grey Scale | 10bits/1024levels |
| Color Capacity | 1.07billion |
| Maximum Power Consumption | 860W/m² |
| Ave.Power Consumption | 280W/m² |
| Operation Power Source | AC90-260V 50-60HZ |
| Frame Frequency | 60-85HZ |
| Refresh Rate | 240-1000HZ |
| Brightness Adjustment | 0-100% 8 levels automatic |
| Gamma Correction | -5.0-5.0 |
| Correction Scale Level | 16bits |
| Color Temperature | 5000-9300K |
| Brightness Correction | Pixels, Module, Cabinet Correction |
| Input Source Support | Composite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI |
| Control Distance | UTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km |
| Operating Temperature | -40°C - 65°C |
| Operating Humidity | 10-90%RH |
| Operating Life Span | 100,000Hours |
| MTBF | 5000 Hours |
| Protection Ratings | IP43 |
| Out of Control Rate | 0.01% |
Product Authentication
Product Pictures
Product Cabinets
Product Packing Case
Product Note:
The above prices are just for your reference, as you know the led display screen is designated products,different size and functions, prices are different, so before you pay for the order, better talk with our sales and get the exactly quote,
will change the prices for you according to the final quotation.
