Indoor full color p2.5mm 2121smd 32s led display panel high resolution led video wall
1. SMD3-in-1 technology(SMD1514) are used for indoor LED display.
2. Wide view angle: 140 in horizonal and 140 in vertical
3. Special design and advanced SMT technology improves the heat dissipation
4. With high refresh rate controller, guarantee that no scan line when taking photos.
5. Slim and lightweight design.
6. Easy for assembling and connecting with fast lock and the connector added.
7. High color uniformity and clear image can bring you a vivid audio visual effect.
8. Items: P1.5,P1.92,P2,P2.5 etc.
1.High quality LED chip and high anti-static electricity capacity.
2.Large viewing angle and smooth displaying provide excellent visual effect from every angle.
3.The integration of lamp and driving IC,together with with the multi-circuit structure,achievs evenly-distributed current,low power consumption and fast heat dissipation.
4.Ultra high brightness,low attenuation,high reliability and weather ability.
5.High contrast ratio.Adopting black lamps can improve the contrast ratio by 50%.
6.High refresh rate,high gray scale,ghost-canceling,low power consumption,low EMI,anti-creeping,multi-route redundancy backup-supporting,and dot-by-dot-calibration.
Main Features:
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
| Item | P1.667 | P1.923 | P2 | P2.5 |
| LED type | SMD0707(3 in 1) | SMD1010(3 in 1) | SMD1010(3 in 1) | SMD1010(3 in 1) |
| Pixel pitch(mm) | 1.667 | 1.923 | 2 | 2.5 |
| Module resolution(W x H) | 120 x 180 | 104 x 156 | 100 x 150 | 80 x 120 |
| Module size(mm) | 200(W) x 300(H) | 200(W) x 300(H) | 200(W) x 300(H) | 200(W) x 300(H) |
| Module weight(kg) | 0.4 | 0.4 | 0.4 | 0.4 |
| Module max.power consuption(W) | 70 | 50 | 50 | 40 |
| Cabient Module composition(W x H) | 2 x 1 | 2 x 1 | 2 x 1 | 2 x 1 |
| Cabient resolution(W x H) | 240 x 180 | 208 x 156 | 200 x 150 | 160 x 120 |
| Cabient size(mm) | 400(W) x 300(H) x 66(D) | 400(W) x 300(H) x 66(D) | 400(W) x 300(H) x 66(D) | 400(W) x 300(H) x 66(D) |
| Cabient area(m2) | 0.12 | 0.12 | 0.12 | 0.12 |
| Cabient weight(kg) | 4.6 | 4.6 | 4.6 | 4.6 |
| Cabient pixel density(dots/m2) | 360000 | 270422 | 250000 | 160000 |
| Cabient flatness(mm) | ≤0.2 | 0.4 |
0.4 | 0.4 |
| Maintenance type | Back maintenance | Back maintenance | Back maintenance | Back maintenance |
| Cabient material | Die casting aluminum | Die casting aluminum | Die casting aluminum | Die casting aluminum |
| Single point brightness calibration | Support | Support | Support | Support |
| White balance brightness | Support | Support | Support | Support |
| Color temperature(K) | ≥1000(Color temperature6500K) | ≥1000(Color temperature6500K) | ≥1000(Color temperature6500K) | ≥1000(Color temperature6500K) |
| Viewing angle(horizontal/vertical°) | 160/160 | 160/160 | 160/160 | 160/160 |
| Luminous piont center distance deviation | <3% | <3% | <3% | <3% |
| Brightness/Color uniformity | ≥97% | ≥97% | ≥97% | ≥97% |
| Contrast ratio | 4000:1 | 4000:1 | 4000:1 | 4000:1 |
|
Max.power(W/Cabient;W/ m2 ) |
150;1200 | 120;1000 | 120;1000 | 95;791 |
|
Average.power(W/Cabient;W/ m2 ) |
35;300 | 29;280 | 29;280 | 29;222 |
| Working voltage | AC90~264V 47-63(Hz) | AC90~264V 47-63(Hz) | AC90~264V 47-63(Hz) | AC90~264V 47-63(Hz) |
| Security Standard | GB4943/EN60950 | GB4943/EN60950 | GB4943/EN60950 | GB4943/EN60950 |
| Frame change frequency(Hz) | 50&60 | 50&60 | 50&60 | 50&60 |
| Driving mode(constant current) | 1/30 Scan | 1/26 Scan | 1/30 Scan | 1/30 Scan |
| Grey scale | 1638 | 1638 | 1638 | 1638 |
| Refersh rate(Hz) | ≥2000 | ≥2000 | ≥2000 | ≥2000 |
| Data processing | 16bit | 16bit | 16bit | 16bit |
| Module take off electricity storage capabilities | Save brightness,color calibration data,module parameter | Save brightness,color calibration data,module parameter | Save brightness,color calibration data,module parameter | Save brightness,color calibration data,module parameter |
| Video definition | 2K,4K UHD | 2K,4K UHD | 2K,4K UHD | 2K,4K UHD |
| Typical life span(hrs) | 50,000H | 50,000H | 50,000H | 50,000H |
| Working environment(℃/RH) | -10~40/10%~80%RH (non condensing) | -10~40/10%~80%RH (non condensing) | -10~40/10%~80%RH (non condensing) | -10~40/10%~80%RH (non condensing) |
| Storage environment (℃/RH) | -20~60/10%~85%RH (non condensing) | -20~60/10%~85%RH (non condensing) | -20~60/10%~85%RH (non condensing) | -20~60/10%~85%RH (non condensing |
