P6 Indoor Led Display Screen Die-casting Cabinet Billboard Price
1. indoor & outdoor stage background
2. Presentation, full color video
3. TV studio. graphics display
4. Multi-media advertising board.etc...
(1) Light. Cabinet size of 512*512mm and light weight of only 12.5 kg enable one-person installation easier and simpler, save installation time. But traditional HD stage led display is over 25 Kg with the same size.
(2) Thin. Adopting the die-casting aluminum, it is high strength, high tenacity, high accuracy and not easy to distort. The thickness of our cabinet is 87mm, the traditonal cabinet is 160mm.
(3) Quick. Adopting quick locking mechanism on the Up, down, left and right connection. Tighten two cabinet up with pull and turn the two handles by 90 degrees. You can install one cabinet with high accuracy in 10 seconds. Cabinet splicing and wiring connection is fast and reliable. Not only beautiful appearance but also a real sense of the rapid disassembly.
(4) Easy. Adopting modular design, assembled cabinet can install and disassembly quickly and easily. It is easy to maintenance.
(5) Compatible. New structure design, can satisfy hoisting, overstow, indoor and outdoor used requirements. Cabinet simplification, and various pixel pitch of indoor and outdoor mudules such like P4, P5.33, P6.4, P8, P10.66, P12.8, P16 are compatible.
(6) Low. Has excellent heat dissipation design and performance. it is low noise and doesn't need external fan or air-condition. With the features of lighweight and low power consumption, it can reduce the labor cost of installation and operating costs.
More information about portable stage background led display, please go to .
concerning public information release platform, traffic monitoring and scheduling, military command authorities, video conference system, television studio, senior shopping mall......
Item |
P6 |
Pixel Pitch |
6mm |
Pixel Configuration |
1R1G1B |
LED Encapsulation |
SMD3528 |
Pixel Density |
27777 dot |
Brightness |
1500 cd |
Color temperature |
7000 - 8800 K |
Scan mode |
1/8 |
Unit cabinet |
576/ 576X 70mm |
Unit cabinet Resolution |
96X96 |
Cabinet weight |
11 Kgs |
Max. Power Consumption |
760 |
Aver. Power Consumption |
330 |
Viewing angle |
H:140°V:140° |
Refresh rate |
> 900Hz |
Gray grade |
16bit |
Best Viewing distance |
6- 80M |
Cabinet Material |
Steel or Aluminum |
Power Input |
AC: 80-265V, 47- 63Hz. |
Working Tem./Hum. |
-25-50℃/ 10%~90% |
Operating System |
Andriod/ Windows |
