high transparency led display xxxx china music video wall

Specifications

1.P20 video Advertising Billboard outdoor curtain wall led display
2.Big viewing angle
3.High brightness
4.2 years warranty

high transparency led display xxxx china music video wall



Feature and Advantage



LED display, LED screen, LED wall, large display, board sign, advertising display, display board, LED board display, outdoor signs, LED outdoor, screen outdoor, video display board, display panel board

Key Benefits:
1. High brightness and adjustable the need of the changing requirement of customer in environment;
2. Having good lightening accordance and no mosaic;
3. Using virtual pixels, better viewing effect for both text & graphic and video;
4. Having larger viewing angle: Horizontal angle 160 degree/elevation angle 70 degree. Getting vivid effect within any position of the viewing range;
5. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.



Our service



1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.



Trade Terms



1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:1sqm

5.Delivery time: 15days after receive pre-payment



LED Screen Parameter



Description	Technical parameter
Unit module	Module size	256*256mm
	Pixel pitch	16mm
	Pixel density	3906dots/sqm
	Pixel configuration	1R1G1B
	Led specification	Φ3ellipse
	Pixel resolution	W:16dots*H:16dots
Cabinet	Dimension	1024mm*1024mm*150mm
	Quantities of module	16pcs
	Power supply	4pcs
	Thermal discharge	Fan*4pcs
	Total weight	65kg
	Best viewing distance	10-100m
	Temperature	Storage: -35°C~+85°C
		Working: -35°C~+85°C
	Thickness	15cm can adjustable
	Remarks: cabinet size can changed, upon project need.
Power	Working voltage	AC220V/110V±10%
	Average power consumption	200-300W
	Max. Power consumption	≤800W/sqm
	Current	≤20mA(single LED)
Control system	CPU	Pentium4 or above
	Operating system	WIN98/2000/NT/XP
	Control method	Synchronization
Main technical parameter	Driving device	Static constant current
	Drive type	Constant Current driver IC
	Refresh frequency	≥400Hz
	Grey scale/colors	256 levels of each color(R/G/B)/16.7M color
	Brightness of white balance	More than 8000cd/sqm
	Brightness adjustment	256 levels of each color(R/G/B)by software
	Operating ambient humidity	10%--95%
	Video signal	PAL/NTSC
	Control system	DVI display card+full color controller card
	MTBF	≥10,000hours
	Life span	≥100,000hours
	Flatness	Tolerance of interpixel ≤0.3mm
		Tolerance of modules clearance≤0.6mm
	Power switch	Automatic switch
	Display mode	1024*768
Software	LED media player



High quality LED lamps material











High quality led connectors











LED Control system diagram



LED display certificates









Working factory:







Applications:
