Specifications
1.P20 video Advertising Billboard outdoor curtain wall led display2.Big viewing angle
3.High brightness
4.2 years warranty
pitch 4mm led video wall
Feature and Advantage
LED display, LED screen, LED wall, large display, board sign, advertising display, display board, LED board display, outdoor signs, LED outdoor, screen outdoor, video display board, display panel board
Key Benefits:
1. High brightness and adjustable the need of the changing requirement of customer in environment;
2. Having good lightening accordance and no mosaic;
3. Using virtual pixels, better viewing effect for both text & graphic and video;
4. Having larger viewing angle: Horizontal angle 160 degree/elevation angle 70 degree. Getting vivid effect within any position of the viewing range;
5. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win
6. Export countries : Peru, Mexico, Colombia, Turkey, US, UK, etc.
Trade Terms
1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm
5.Delivery time: 15days after receive pre-payment
LED Screen Parameter
Description |
Technical parameter |
|
Unit module |
Module size |
256*256mm |
Pixel pitch |
16mm |
|
Pixel density |
3906dots/sqm |
|
Pixel configuration |
1R1G1B |
|
Led specification |
Φ3ellipse |
|
Pixel resolution |
W:16dots*H:16dots |
|
Cabinet |
Dimension |
1024mm*1024mm*150mm |
Quantities of module |
16pcs |
|
Power supply |
4pcs |
|
Thermal discharge |
Fan*4pcs |
|
Total weight |
65kg |
|
Best viewing distance |
10-100m |
|
Temperature |
Storage: -35°C~+85°C |
|
Working: -35°C~+85°C | ||
Thickness |
15cm can adjustable |
|
Remarks: cabinet size can changed, upon project need. | ||
Power |
Working voltage |
AC220V/110V±10% |
Average power consumption |
200-300W |
|
Max. Power consumption |
≤800W/sqm |
|
Current |
≤20mA(single LED) |
|
Control system |
CPU |
Pentium4 or above |
Operating system |
WIN98/2000/NT/XP |
|
Control method |
Synchronization |
|
Main technical parameter |
Driving device |
Static constant current |
Drive type |
Constant Current driver IC |
|
Refresh frequency |
≥400Hz |
|
Grey scale/colors |
256 levels of each color(R/G/B)/16.7M color |
|
Brightness of white balance |
More than 8000cd/sqm |
|
Brightness adjustment |
256 levels of each color(R/G/B)by software |
|
Operating ambient humidity |
10%--95% |
|
Video signal |
PAL/NTSC |
|
Control system |
DVI display card+full color controller card |
|
MTBF |
≥10,000hours |
|
Life span |
≥100,000hours |
|
Flatness |
Tolerance of interpixel ≤0.3mm |
|
Tolerance of modules clearance≤0.6mm | ||
Power switch |
Automatic switch |
|
Display mode |
1024*768 |
|
Software |
LED media player |
|
High quality LED lamps material
High quality led connectors
LED Control system diagram
LED display certificates
Working factory:
Applications:
