ads for CMCC P16 full color wall mounted led display
- 10000 Square Meter / Square Meters per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Guangdong, China | Brand Name: | JC | Model Number: | JC-FSO-PH10MM |
Usage: | Outdoor | Tube Chip Color: | Other, ads for CMCC P16 full color wall mounted led display | Display Function: | Graphics |
Pixels: | Other, ads for CMCC P16 full color wall mounted led display | Screen Dimension: | 960mmx960mm |
Product Description
Specifications
1.ads for CMCC P16 full color wall mounted led display2.Big viewing angle
3.High brightness
4. 2 years warranty
ads for CMCC P16 full color wall mounted led display
Quick Details
1. hot sale p10 outdoor led display screen module size:160mm*160mm
2. Brightness:7000cd/sqm
3. Pixel density:10000dots/sqm
4. Average Power:185w/sqm
5. IP rate: IP67 full waterproof
6. Design life:100000hours
Feature and Advantage
1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system
2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system
3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof your LED display screen's investment.
4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win
6. Export countries : Peru, Mexico, Colombia, Turkey, US, UK, etc.
Trade Terms
1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm p10 outdoor led display
5.Delivery time: 10 days after receive pre-payment
LED Screen Parameter
Module:P10 | LED Type | DIP346 | |
Pixel Pitch | 10mm | Refresh frequency | 1,500Hz |
Module Size | 160x160mm | View Angle | 1100/750 |
Module resolution | 16x16pixel | Working Environment | Temp:-20°C~60°C, Humidity:10%~90% |
Dot density | 10,000pixel/sq. m | Working Voltage | AC:100V~120V AC:220~240V |
Pixel configuration | 1R1G1B | Lifetime | 100,000Hours |
The best view distance | 10-100M | Gray Scale | 14bit/color |
Cabinet dimension | 960mmx960mm(Optional) | Color Display | 1.07Billion |
Cabinet resolution | 96X96 | Brightness | ≥7000nit |
Cabinet weight | 58KG/sq. m | MITBF | 0.00001 |
Drive mode | Constant current,1/4 Scan | IP | IP65 |
Max Power Consumption | 600W/sq. m | Warranty | 2 year |
LED Parameter | R:d(625-630nm) R:IV(400-450mcd) | G:d(522.5-525nm) G:IV(1800-2200mcd) | B:d(467.5-470nm) B:IV(350-400mcd) |
Image adjustment | Brightness, contrast, tone, color range etc | ||
Brightness uniformity | Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness) | ||
Effective control distance | Cat 5<100M / Multi-mode fiber:<500M / Single-mode fiber<20Km | ||
Color Temperature/contrast | Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable | ||
Input signal | RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION | ||
Control system | Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional) |
High quality LED lamps material
High quality led connectors & LED Control system diagram
LED display certificates
Working factory:
Applications:
