Energy Saving Full Color HD LED Video Display Screen Organic Glass Led Display

Energy Saving Full Color HD LED Video Display Screen Organic Glass Led Display thumbnail-1
Energy Saving Full Color HD LED Video Display Screen Organic Glass Led Display photo-1
US$ 950 - 2,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JC
Model Number:
JC-FSO-PH4MM
Contact Supplier Request Quote Chat Now
Shenzhen Jingcan Opto-Tec Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name JC
Model Number JC-FSO-PH4MM
Usage Indoor
Tube Chip Color Full Color
Display Function Graphics
Pixels Other, indoor electronic advertising led display screen
Screen Dimension 512mmx512mm

Specifications

1.indoor electronic advertising led display screen
2.Big viewing angle
3.High brightness
4.2 years warranty
5.CE, RoHS.

Energy saving full color HD LED video display screen organic glass led display






Feature and Advantage



1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system

2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system

3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof  your LED display screen's investment.

4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.

5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.



Our service





1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.



Trade Terms



1.Payment: T/T 35% as deposits before production, T/T 65% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:1sqm p7.62 one line english led message signboard

5.Delivery time: 10-15days after receive pre-payment



LED Screen Parameter



Technical DataModel PH4
Pixel Pitch 4mm
Physical Density(pixels/m²) 62500
LED Shape & Size SMD 3 in 1
LED Arrangement 1R1G1B
Module Size(mm) 128×128
Module Resolution 32*32
Drive Mode Dynamic 1/8 Duty Constant Current
Brightness ≥1500cd/m²
Contrast(cd/m²) ≥2000:1
View Angle, 50% Brightness 140°/140°
Minimum View Distance 4m
Grey Scale 10bits/1024levels
Color Capacity 1.07billion
Maximum Power Consumption 860W/m²
Ave.Power Consumption 280W/m²
Operation Power Source AC90-260V 50-60HZ
Frame Frequency 60-85HZ
Refresh Rate 240-1000HZ
Brightness Adjustment 0-100% 8 levels automatic
Gamma Correction -5.0-5.0
Correction Scale Level 16bits
Color Temperature 5000-9300K
Brightness Correction Pixels, Module, Cabinet Correction
Input Source Support Composite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI
Control Distance UTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km
Operating Temperature -40°C - 65°C
Operating Humidity 10-90%RH
Operating Life Span 100,000Hours
MTBF 5000 Hours
Protection Ratings IP31
Out of Control Rate 0.01%

 Energy saving full color HD LED video display screen organic glass led display

indoor SMD video full color led screen information panel billboards

indoor SMD video full color led screen information panel billboards

indoor SMD video full color led screen information panel billboards

indoor SMD video full color led screen information panel billboards

Energy saving full color HD LED video display screen high quality video

Energy saving full color HD LED video display screen high quality video

Energy saving full color HD LED video display screen high quality video

Energy saving full color HD LED video display screen high quality video

Energy saving full color HD LED video display screen high quality video

Energy saving full color HD LED video display screen high quality video
