Specifications
CE Certificate Good EPS Styrofoam Machine Price:Controlled by PLC and touch screen
With vacuum and hydraulic system
CE Certificate Good EPS Styrofoam Machine Price
Advantage:
-1 year quality guarantee, spare part for free
- 2 engineers go to install EPS production line
I. EPS shape production line mainly includes 3 parts:
1. EPS pre-expander: it’s used to make EPS raw material to foamed beads
2. EPS shape molding machine: it’s used to make foamed beads to kinds of shaped products like foam box, electric & electronic package, ICF, helmet, seed tray, decoration cornice and etc.
3. Mould:it’s hang in the shape molding machine to make different products.
Working flow of CE Certificate Good EPS Styrofoam Machine Price
A.EPS pre-expander
It turns eps raw material (expanded polystyrene) to big and light foam beads through steam heating. With PLC and touch screen to realize full automatic production for feeding, heating and ejecting foam beads.
ITEM |
HPS-11100B |
|
Expansion Chamber |
Diameter |
DN1100 |
Volume |
1.4m3 |
|
Usable Volume |
1.0m3 |
|
Steam |
Entry |
DN50 |
Consumption |
6-8kg/cycle |
|
Pressure |
0.6-0.8Mpa |
|
Compressed Air |
Entry |
DN25 |
Consumption |
0.9-1.1m3/cycle |
|
Pressure |
0.5-0.8Mpa |
|
Drainage |
Upper Drain Port |
DN100 |
Down Drain Port |
DN100 |
|
Material Conveying Line |
DN150 |
|
Capacity |
10.5g/l 350kg/h |
|
15g/l 580kg/h | ||
20g/l 800kg/h | ||
30g/l 950kg/h | ||
Connected Load/Power |
19.5KW |
|
Expanded Density |
10-40kg/m3 |
|
Density Tolerance |
<±2% |
|
Overall Dimension |
2900*4500*5900(mm) |
|
Weight |
3200kg |
|
B. EPS molding machine
The machine applies PLC and touch screen with advanced molding technique can produce various shapes of EPS products, the vacuum and hydraulic system can increase molding speed and reduce cooling time
Item |
HPS-1200A |
HPS-1400A |
HPS-1600A |
HPS-1800A |
Mould size |
1200*1000mm |
1400*1200mm |
1600*1350mm |
1760*1460mm |
Produce size(mm) |
1050*850*350 |
1200*1050*350 |
1420*1200*350 |
1580*1320*350 |
Minimum mould thickness |
200mm |
210mm |
220mm |
230mm |
Stroke speed |
210mm/second |
190mm/second |
140mm/second |
140mm/second |
Steam entry |
DN65 |
DN80 |
DN80 |
DN80 |
Water entry |
DN65 |
DN65 |
DN65 |
DN65 |
Compressed air entry |
DN40 |
DN40 |
DN50 |
DN50 |
Vacuum pump capacity |
165m3/h |
230m3/h |
280m3/h |
280m3/h |
Power |
10.6kw |
14.1kw |
14.5kw |
14.5kw |
Machine size(mm) |
4500*1840*2900 |
4600*2140*3100 |
5000*2300*3400 |
5000*2450*3600 |
Weight |
4600kg |
4900kg |
5700kg |
6000kg |
Application of CE Certificate Good EPS Styrofoam Machine Price
C. Moulds
Standard export packaging:
Outer package: standard export wooden cases.
Inner package: plastic paper or wrapped with stretch film and etc.
Shipment:
By sea from Shanghai or Ningbo port
By train from Ningbo station
By truck from Kashgar, Urumuqi or other checkpoint
1. Take our valued client as priority, make sure equipment quality and answer clients’ questions anytime and anywhere.
2. Customizing machines according to clients' needs, such as different design, different brand parts, different colors, more function and etc
3. Engineers go to clients' factory to install machines in time.
4. More spare parts given to clients for free to ensure the factory working without suddenly stop
Q: Does your machine have CE certification?
A: Yes,our machine with CE certification.
Q: How about payment terms?
A: 30% TT deposit + 70% TT before shipment,50% TT deposit + 50% LC balance, Flexible payment can be negotiated.
Q: Installation and commissioning?
A: We will send our engineer for installation and commissioning, but relevant cost will be paid by you.
Q: Do you have some videos where we can see the line producing?
A: Yes, we can provide some videos for reference.
