Home > Manufacturing & Processing Machinery > Building Material Making Machinery > Board Making Machine > Infrared Fully Automatic Machine, Make Macking for Stone Tiles
Infrared Fully Automatic Machine, Make Macking for Stone Tiles
US$ 22,000 - 24,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TIAN JUN
Model Number:
TJQH-1000
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TJQH-1000 Infrared Fully Automatic Bridge Type Edge Cutting MachineUS$ 18,000 - 25,000MOQ: 1 Set -
Bridge Type Edge Cutting Machine (saw Machine)NegotiableMOQ: 1 Set
-
Manual Stone Tile Cutting MachineUS$ 5,600 - 6,000MOQ: 1 Set
-
LCHW-1200 Bridge Type Edge Cutting MachineUS$ 16,000 - 18,000MOQ: 1 Set
-
Automatic Infrared Fully Bridge Type Edge Cutting Machine,stone Cutting MachineUS$ 17,200 - 17,800MOQ: 1 Unit
Place of Origin
Fujian, China
Brand Name
TIAN JUN
Model Number
TJQH-1000
After-sales Service Provided
Overseas service center available
Specifications
Automatic machine for making tiles1. Blade diameter: 600-800-1000mm
2. Main motor: 18.5kw
3. Worktable size: 3200*2000mm
|
Infrared Fully Automatic machine, make macking for stone tiles
Automatic operation machine for making stone tiles, cutting in accuracy way, faster work.
Technical data | |||||||||
| Name | unit | TJQH-1000 | |||||||
| Blade diameter | mm | Φ600-Φ800-Φ1000 | |||||||
| Blade up/down stroke | mm | 400 | |||||||
| Main motor | kw | 18.5 | |||||||
| Feeding motor | kw | 1.5 | |||||||
| Slicing motor | kw | 1.1 | |||||||
| Worktable size (Max.cutting size) | mm | 3200X2000 | |||||||
| Worktable rotation angle(by hydraulic) | 90°or 360° | ||||||||
| Worktable upturning angle | 0°- 85° | ||||||||
| Dimension (LxWxH) | mm | 6300*4700*2800 | |||||||
| Voltage/Frequency | V/HZ | 380V/50HZ | |||||||
| Weight | kg | 6500 | |||||||
Stone edge cutting machine photos:
QUALITY CONTROL:
STONE FAIR:
OUR COMPANY:
OUR CUSTOMERS COVER:
Contact US:
