PMS-1030D 30W mini 12v power amplifier
- 2000 Piece / Pieces per Month
- Guangzhou Shenzhen Qingdao Xiamen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | ARTONE | Model Number: | PMS-1030D |
Product Description
Features
- Built-in MP3 (USB & SD card), FM Tuner and Bluetooth audio sources
- 4 audio sources for selection (MP3/Tuner, Bluetooth and AUX Inputx 2)
- RMS power 30W
- Microphone input x 1
- Volume control for treble, bass, master and microphone
- Reminder chime
- Remote control for MP3 player
- AC 220~240V (Asian or European power) or 110V (for American power) & DC 12V
- Line out for external amplifier
- Speaker output 4-16 ohm, 70V and 100V
- Compact design, able to set up on desk or table
- Economical series with best cost-effective performance
The Multisource Mixer Amplifier PMS-1030D is designed in compact and economic, have power rating at 30W-80W. They are featured of 4 audio source inputs, two of which are aux inputs, one is MP3/FM input and one is bluetooth player. One microphone input on front panel allows paging during the background music is playing.
Individual volume controls are provided for treble, bass and Mic, master volume control are provided for overall tone control. 70V, 100V and low impedance 4-16 ohms speaker outputs are provided. Extensive protection from short-circuit, overload and high temperature.
Application and Use Places
ARTONE Multisource Mixer Amplifier PMS-1030D is ideal to use in commercial places like shops, stores, classroom, workshop, offices, church, conference, wine bar, restaurants or any room which is less than 200 square meter, sufficient use for background music and give speech.
PMS-1030D USB FM Radio Bluetooth 12V PA Audio Mixing Power Mini Amplifier has as many as 4 audio source inputs, MP3 (USB or SD card), FM Tuner, Bluetooth and 2 AUX inputs to select from, plug and play, easy and quick to set up a small pa system for your places, fulfill the space with music and announcement.
Specification
| Model No. | PMS-1030D USB FM Radio Bluetooth 12V PA Audio Mixing Power Mini Amplifier |
| Power and Power Tap | 30W |
| Speaker Outputs | 4-16Ω, 70V, 100V |
| Input Sensitivity | Mic: 5mV/600Ω unbalanced 6.3mm phone jack inputAUX:350mV/10KΩ RCA input |
| Output Sensitivity & Impedance | 1000mV/470Ω, Unbalanced RCA output |
| Frequency Response | 50-16KHz (+1dB, -1dB) |
| S/N Ratio | Mic:66dB / AUX:80dB |
| THD | Less than 0.1% at 1KHz, 1/3 rated power |
| Audio Source | MP3 (USB/SD), Tuner, Bluetooth, AUX input x 2 |
| Cooling Method | Fan cooling |
| Protection | High temp, overload & short-circuit |
| Power Supply | 220V-240V 50/60Hz or 110V & DC 12V |
| Power Consumption | 50W |
| Material and Finish | Alu panel, steel case |
| Dimension | 245 x 240 x 70 mm |
| Weight | 4.5KG |
Related Products
First Packing: Plastic Bag (to prevent it from scratch);
Second Packing: Foam Packing (Anti Vibration or serious shock in transportation)
Third Packing: Carton Box (For easier delivery and selling)
Forth Packing: General Packing for 5 pieces amplifier, for fast loading and handling
