PMS-A5080A Mps Usb fm 80w 4 Audio Sources Public Address 5 Zone Amplifier

PMS-A5080A Mps Usb fm 80w 4 Audio Sources Public Address 5 Zone Amplifier thumbnail-1
PMS-A5080A Mps Usb fm 80w 4 Audio Sources Public Address 5 Zone Amplifier thumbnail-2
PMS-A5080A Mps Usb fm 80w 4 Audio Sources Public Address 5 Zone Amplifier photo-1
PMS-A5080A Mps Usb fm 80w 4 Audio Sources Public Address 5 Zone Amplifier photo-2
US$ 72.66 - 398 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ARTONE
Model Number:
PMS-A5080A/PMS-A5120A/PMS-A5180A/PMS-A5240A
Contact Supplier Request Quote Chat Now
Guangzhou Wepal Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Canton Shenzhen Ningbo Qingdao Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ARTONE
Model Number PMS-A5080A/PMS-A5120A/PMS-A5180A/PMS-A5240A
 PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifierPMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier

Features

  • Built-in MP3 (USB), FM Tuner and AUX input x3 audio sources
  • 5 Zones amplifier, individual volume control for each zone
  • RMS power 80W, 120W, 180W, 240W
  • Microphone input x 2
  • Volume control for treble, bass, master and microphone
  • Reminder chime
  • Remote control for MP3 player
  • AC 220~240V (Asian or European power) or 110V (for American power)
  • Line out for external amplifier
  • Speaker output 4-16 ohm, 70V and 100V
  • Slim design, able to set up on desk or table, also available for mounting on cabinet or racks
  • Economical series with best cost-effective performance

Description


The 5 Zone Multisource Mixer Amplifier  PMS-A5080A/PMS-A5120A/PMS-A5180A/PMS-A5240A is designed in slim and economic, have power rating at 80W, 120W, 180W and 240W. They are featured of several audio source inputs, two of which are aux inputs, and MP3 / Tuner player. 2 microphone inputs on front panel allows paging during the background music is play to 5 zones.

Individual volume controls are provided for treble, bass and Mic, 3 zones and master volume control are provided for overall tone control. 70V, 100V and low impedance 4-16 ohms speaker outputs are provided. Extensive protection from short-circuit, overload and high temperature.



Application and Use Places


ARTONE 5 Zone Multisource Mixer Amplifier PMS-A5080A/PMS-A5120A/PMS-A5180A/PMS-A5240A is ideal to use in commercial places like shops, stores, classroom, workshop, offices, church, conference, wine bar, restaurants or any room which is less than 200 square meter, sufficient use for background music and give speech.

The PMS-A5080A/PMS-A5120A/PMS-A5180A/PMS-A5240A has as many as 4 audio source, MP3 (USB), FM Tuner and 2 AUX inputs, plug and play, easy and quick to set up a 5 zone pa system for your places, fulfill the space with music and announcement.

PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier

Specification


Model No.      PMS-A5080A/PMS-A5120A/PMS-A5180A/PMS-A5240A
Power and Power Tap      80W, 120W, 180W, 240W
Speaker Outputs      4-16Ω, 70V, 100V
Input Sensitivity      Mic: 5mV/600Ω unbalanced 6.3mm phone jack inputAUX:350mV/10KΩ RCA input
Output Sensitivity & Impedance             1000mV/470Ω, Unbalanced RCA output
Frequency Response      50-16KHz (+1dB, -1dB)
S/N Ratio      Mic:66dB / AUX:80dB
THD      Less than 0.1% at 1KHz, 1/3 rated power
Audio Source      MP3 (USB), Tuner, AUX input x 2
Cooling Method      Fan cooling
Protection      High temp, overload & short-circuit
Power Supply      220V-240V 50/60Hz or 110V
Power Consumption      120W, 140W, 210W, 300W
Material and Finish      Alu panel, steel case
Dimension      487 x 310 x 70 mm
Weight      5.5KG, 7KG, 8KG, 8.5KG

Related products
PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier         PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier         PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier          PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifierPMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier          PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier         PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier         PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier
Packaging & Shipping

First Packing: Plastic Bag (to prevent it from scratch);

Second Packing: Foam Packing (Anti Vibration or serious shock in transportation)

Third Packing: Carton Box (For easier delivery and selling)


Our Services
Product Quality Level High & Medium Quality Provided
Price & Cost Low price, low profit
Service 7x24 online, OEM/ODM cooperation

PMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifierPMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifierPMS-A5080A mps usb fm 80w 4 audio sources public address 5 zone amplifier
