Home > Products > New Products > Oilfield ZH-2 Mud Logging Unit
Oilfield ZH-2 Mud Logging Unit
- 10 Set / Sets per Month
- Tianjin Shanghai
- T/T
Product Details
| Place of Origin: | Shandong, China | Brand Name: | SINOTAI | Model Number: | EXPLORER ZH-2 |
Packaging Details
Container Packaged
Product Description
Specifications
Oilfield ZH-2 Mud Logging Unit1. Explosion-proof
2. Advanced data transmission system
3.Convenient and flexible
Oilfield ZH-2 Mud Logging Unit
Product Explanation:
EXPLORER ZH-2 is the new generation Mud Logging Unit .It is the leading product of “EXPLORER” series. The mass production of ZH-2 was started at 2005. The hardware configuration of ZH-2 is flexible and the software is fully functional. It is convenient and flexible for user to operation. The geological steering system is optional. The whole performance has reached the world advanced level. Now ZH-2 is one of the dominant mud logging equipment of SINOPEC.
Product types and specifications of mud logging unit:
Module | Type | Technical Specifications |
Container | DNV Certified Positive Pressure Explosion-Proof Container | Suitable for zone I on rig site. DNV A0 grade,IEC79-13 standard. |
Data Acquisition System | RS-485 Data Acquisition System | Explosion proof product,40 analog signal channel,14 pulse signal channel. |
Chromatograph | SLSP-2K Fast Gas Chromatograph | Minimum detectable concentration: 10ppm,Cycle time: ≥30 s. |
CO2 Analyzer | SL-IR-II CO2 Analyzer | Minimum detectable concentration: 0.2%. |
Mud Logging Software | SS-2 Mud Logging Software System | Alarm: rotating red light, buzzer113-138dB, power≥50W. |
Alarm System | SL-SAS Safety Alarm System | Alarm: rotating red light, buzzer113-138dB, power≥50W. |
Other Module | Directional Well Geologic Steering System (selectable) | Modeling geological profile and stacking the well track. The remote collaborative analysis and decision making. |
Real Time Data Remote Transmission System(selectable) | Wireless Network: 3G network, GPRS network, CDMA network.Data Transmission: synchronization with the on-site data. |
Company Profile
As a professional supplier of OCTG, drilling equipment and workover service, Sinotai Petroleum Equipment Co., Ltd. lies in the production base of petroleum equipment and China's second largest oil field --Shengi Oilfield. Our company is a high-tech enterprise in Dongying City with business scope covering the sale, trading, post-sale service and technological development of a wide variety of petroleum equipment.
Besides OCTG, we provide our customers with other drilling and oil recovery equipment like fishing tools, cementing tools, workover rigs, pumping units and OCTG accessories.
The striving target of our company is "Prestige first, Quality supreme; The shortest delivery time, The lowest price, The best quality". Customers' needs are our first priority and customer satisfaction is the bottom line by which we measure our success.
