Mud Tank for Drilling Fluid System

Specifications

1.Type FG and ZG Mud Tank is devided into Square tank and Cone-shaped tank according to

the shape of tank bottom.

2.The body of the tank is made of welding the steel plate and section, using the flat

cone-shape structure or the corrugated structure.

3. The mud tank surface and the passage are made of the slipping resistant steel plate and

linearity netted steel plate which is produced by the professional factory, the

mud tanks are made of the side steel pipe, all of the structure can be folded

without barrier and pegged reliably.

4.The surface of tank is equipped with water pipeline for cleaning the surface and

equipment on the mud tank, we use soaked zinc processing for the netted steel

plate.

5.The ladder is made of the channel steel to take responsibility the body, the foot

board is made of the linearity netted steel plate.

6.The two-sided guard rail are installed the safe suspension hook. The mud tank is

designed the standard shanty to prevent the sand and the rain.

7.The pipeline is installed in the tank to preserve the warm air heat.
