Specifications
Meet API Spec 8A/8C standardCE/ISO certificate.
Top quality and best price.
Vacuum Degasser
Vacuum Degasser
1.ZCQ series Vacuum Degasser is a special-purpose device and a new type one for the treatment of gas
in the drilling fluids.
2.It can get rid of various gas of invasive drilling quickly. Vacuum degasser is very important for
returning mud gravity, stabilizing mud viscosity and reducing drilling cost.
3.vacuum degasser can be used as a heavy-power agitator and supported applicable to all types
of mud circulation purification system.
4.The vaccum degasser design of the structure is scientific and rational. So we are able to achieve an effective gas-liquid separation, filter out impurities and to ensure that the exhaust pipe is always smooth.
ZCQ series Vacuum Degasser Technical Parameters:
Model |
ZCQ240 |
ZCQ270 |
ZCQ300 |
ZCQ360 |
Main diameter |
700mm |
800mm |
900mm |
1000mm |
Capacity |
≤240 m3/h |
≤270 m3/h |
≤300 m3/h |
≤360 m3/h |
Vacuum |
-0.030~-0.045MPa |
-0.030~-0.050MPa |
-0.030~-0.055MPa |
-0.040~-0.065MPa |
Ratio |
1.68 |
1.68 |
1.68 |
1.72 |
Efficiency |
≥95% |
≥95% |
≥95% |
≥95% |
Motor power |
15kW |
22kW |
30kW |
37kW |
Vacuum Power |
2.2kW |
3kW |
4kW |
7.5kW |
Rotary speed |
860/r/min |
870/r/min |
876/r/min |
880/r/min |
Dimension |
1750×860×1500 |
2000×1000×1670 |
2250×1330×1650 |
2400×1500×1850 |
Weight |
1100kg |
1350kg |
1650kg |
1800kg |
