Introductions:
CS995 Type High-frequency infrared carbon sulphur analyzer compatible applying with WF-T88 Type High frequency automatic inductive combustion furnace, can fleetly and exactly measure the carbon and sulfur in steel, iron, alloy, nonferrous metals, cement, ore and other materials. This equipment is a high-tech products integrate light, motor, electronic, computer and analysis technology, with features of wide measuring scope, strong anti interference, multiple function, easy to operate, accurate and reliable analysis result.
Main Parameter:
Measure Range:
Carbon: w(C) 0.0005%-6.0000% (can be extended to 99.999%)
Sulpher: w(C) 0.0005%-0.5000% (can be extended to 99.999%)
Sample weight:
standard 0.5g
Analysis Error:
Carbon: accord with ISO9556 standard
Sulfur: accord with ISO4935 standard
Analysis Precision:
Carbon: RSD<1%
Sulfur: RSD<1.5%
Analysis pool
Carbon: one pool
Sulfur: one pool
Time of analysis:
25 to 60 seconds, could be adjusted. Around 35 seconds usually
Sensitivity(The minimum readings):
C/S 0.1ppm
Electronic scale:
Precision of read: 0.0001g
Working Environment:
Room temp: 10 to 30 degree C,relative Humidity less than 75%
Analytical gas path system
Gas path: |
The high precision flow controller ensures the stability of gas flow as well the gas intake system (such as electromagnetic valves, unions, cylinder hoists) for automatic leakage detection. |
|
Dual standard correction for solid and gas |
De-dusting unit: |
The combustion head self-cleaning device effective for reducing the influence of dust for the result of analysis; ash removing system for the inlet. |
|
0.4 μm submicron metal filter secures thorough separation of dust from gas and can be used for a long time with no need of the ultrasonic cleaner. |
Software
Training
Scene technical training
Party A is responsible for party B of the operation and maintenance, daily breakdown training, ensure the worker of party B can operate instrument independently.
System training
The party B can send staff to party A system training, two staffs, five days(Training specific time agreed both sides) transport, accommodation self-care. Training includes:
♦Principles and methods of instrumental analysis
♦The structure and features of the instrument
♦Quantitative analysis of instrument (iron and steel material)
♦Analysis conditions set, the working curve, correction, etc.
♦Daily breakdown exclusion
♦Instrument Maintenance
Installation of the instrument
Preparation before the installation
Note: The user should make appropriate working preparation before the arrival of company installation staff.
1. Analyzing room: be far away from the erosion gas such as acid, alkali, dust, vibration, testing disturbance.
2. Analyzing room size: more than 3×3m
3.Working condition: Room temperature: 10-30°C, Relative humidity: below 75%
4. Power supply: well earthing is required, Voltage: AC220V±5%, Frequency: 50Hz±2%, No disturbance from harmonic wave
5. Voltage stabilizing equipment: Power: 5kW, Voltage stabilizing precision below 2%
Note: If there is disturbance from intermediate frequency furnace in the work power supply, the equipment should be equipped with AC Regulated Power Supply.
6. Gas: Oxygen: purity more than 99.5%
7. Power gas: Nitrogen or Compressed air (Purified: without water, oil and contamination)
8. Tool: Box opening tool and regular tools.
