Help CenterOilfield SNJ Type Cement Truck Mud Monitoring System-for Workover Operation
Related Products
-
Mud Level Monitor and Grouting SystemUS$ 5,000 - 10,000MOQ: 1 Set -
OIlfield Mud Level Monitor and Grouting SystemUS$ 5,000 - 10,000MOQ: 1 Set
-
Oilfield Drilling Mud Level Monitor and Grouting SystemUS$ 5,000 - 10,000MOQ: 1 Set
-
Oilfield SNK Mud Level Monitor and Grouting SystemUS$ 5,000 - 10,000MOQ: 1 Set
-
Mud Outlet FlowmeterUS$ 4,000 - 8,000MOQ: 1 Set
Specifications
1.Display at real time pump pressure2.Check SPM signal with the system and calculate working time
3.Man-machine interaction
Snj Cement Truck Mud Monitoring System
Application Areas
SNJ Cement Truck Mud Monitoring System is mainly used to meter pump pressure, injection flow and etc. for workover operation or cement truck.
Features
1. Display at real time pump pressure, theoretical transient displacement, theoretical accumulated displacement, actual transient displacement and accumulated displacement, current working time and accumulated working time of pump, current working time and accumulated working time of diesel engine.
2. Display at real time changes of pump pressure vs time for judgment of pressure change.
3. Provide audible alarm when pump pressure is too high and cut off pump clutch (controlled via solenoid valve pneumatic channel) to change working status of pump. When the pressure reaches the limited, the system will give alarm and depressurizing signals. Alarm value can be modified.
4. Check SPM signal with the system and calculate working time and accumulated working time of pump of this time; check signals at D+ terminal of charging generator and judge and calculate working time and accumulated working time of the generator.
5. Measured data can be transmitted to the management computer (Optional) via serial port communication to analyze relevant working status. 24hours’ pump pressure, transient displacement and other working parameters can be stored.
6. Man-machine interaction operation interface makes the operation easy and convenient.
Main Technical Specifications
1. Working temperature: -30 ~ +55°C
2. Working humidity: 0 ~ 95%
3. Pump pressure
(1). Measuring range: 0—40MPa
(2). Accuracy: 0.25%
4. Injection flow rate
(1). Range: 200m3/d
(2). Accuracy: 1%
5. Theoretical flow rate
(1). Range:0~250m3/d
(2). Accuracy: 51%
6. When the pump pressure is about 1MPa to the set pressure, the system will automatically alarm and control the clutch.
