Oilfield SGH2000 Pumping Well Tester
- 300 Set / Sets per Month
- Tianjin Shanghai Qingda etc
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | Sinotai | Model Number: | SGH2000 |
Usage: | Other, well drilling tester |
Packaging Details
according to the requirement
Product Description
Specifications
SGH2000 Pumping Well Tester1.check liquid level
asure electric current diagram
3.paper tapes
4.displayed on LCD
SGH2000 Pumping Well Tester
Application Areas
SGH2000 Pumping Well Tester is mainly used to check liquid level, dynamometer diagram of pumping well, and leakage loss of valve. It can also be used to measure electric current diagram and casing pressure if necessary.
Features
Equipped with automatic timer and person-machine interaction interface.
Wireless dynamometer test and infrared optical code displacement test.
Test results are recorded by paper tapes, displayed on LCD and tracked by graphic curves at real time.
Plays at real-time liquid level and dynamometer diagram on LCD screen, and saves the testing results.
On-line data calibration , USB data communication.
Directly drive printer (Epson) to out print tested data.
Various load sensors (Shutdown type, non-shutdown type) and wellhead connectors(gas sounoler, bulet sounder)for you to choose.
Technical Specifications
Measurable liquid depth:
Casing pressure≤0.5MPa,Maxst measurable level: 3000m
Casing pressure>0.5MPa,Maxst measurable level: 3500m
The chart running speed of the secondary instrument: 100±0.5mm/s
The instability of chart running of the secondary instrument: ±0.2%
Capacity of curves storage:120 dynamometer diagrams and 100 liquid level curves
Load range: 0~140kN Accuracy: ±1%F.S(shutdown type)
0~50kN 0~80kN 0~140kN
Accuracy: ±3%F.S(non-shutdown type)
Displacement: 0~8m Accuracy: ±1%F.S
Distance limit of radio transmission of dynamometer diagrams: 30m
Working temperature: -30~55°C
Dimensions and weights
Primary instrument(non-shatdown type) 200×85×65mm 2.5kg
Secondary instrument 380×260×140mm 9.5kg
