Drilling Site Testing System SH4A-2 Echometer

Drilling Site Testing System SH4A-2 Echometer thumbnail-1
Drilling Site Testing System SH4A-2 Echometer photo-1
US$ 500 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Sinotai
Contact Supplier Request Quote Chat Now
Sinotai Petroleum Equipment Co., Ltd.
Silver Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai Qingdao etc
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name Sinotai
Model Number SH4A-2
Weight 10KG
Dimension(L*W*H) 380*260*160 mm
Certification API
Warranty 18 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

SH4A-2 Echometer
1.rational structure
2. easy operation
pact size
4.high collar detecting rate

SH4A-2 Echometer



Application Areas

1.  SH4A-2 Echometer mainly used to measure depth of dynamic liquid level and depth of static liquid level in pumping wells, and is also used to test casing pressure at well head as required.



Features

2.  SH4A-2 echometer is characterized by rational structure, easy operation, compact size, strong depth-testing capability and high collar detecting rate, etc.



Technical Specifications

 1. Working pressure of primary instrument: 10MPa

 2. Firing success rate of primary instrument: 100%

 3. Chart running speed of the secondary instrument: 100±0.5%mm/s

 4. Instability of the running chart: 0.2%

 5. Measurable liquid level depth (m):

3000m (when the casing pressure ≤0.5MPa)

3500m (when the casing pressure >0.5MPa)

 6. Measurable casing pressure range:0~10MPa

Accuracy: ±1%F.S

 7. Dimensionsnt:

Primary instrument: 61×61×260mm Weight: 3kg

Secondary instrument:380×260×160 mm Weight: 7kg

 8. It can test 100 well times after being fully charged.(A special charger is supplied)

drilling site testing system SH4A-2 Echometer
