Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter

Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter thumbnail-1
Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter thumbnail-2
Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter thumbnail-3
Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter photo-1
Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter photo-2
Computeriezd Automatic Continuously Hydraulic Cutting Paper Machine, Paper Cutter photo-3
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Paper Cutting Machine
Computerized:
Yes
Contact Supplier Request Quote Chat Now
Ruian Tiansheng Packing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Paper Cutting Machine
Computerized Yes
Place of Origin Zhejiang, China
Brand Name Tiansheng
Model Number TSPC1300
Voltage 380V,3Ph,50Hz
Power(W) 4kw
Dimension(L*W*H) 3000*1750*2000mm
Weight 4000kgs
Certification CE and SGS
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Computeriezd automatic continuously hydraulic cutting paper machine, paper cutter



Computeriezd automatic continuously hydraulic cutting paper machine, paper cutterComputeriezd automatic continuously hydraulic cutting paper machine, paper cutter







Automatic continuously hydraulic cutting paper machine, paper cutter

Computeriezd automatic continuously hydraulic cutting paper machine, paper cutter









Usage:

The hydraulic cutting paper machine could be used for cutting various printed paper,

craft paper, glassine, books, cards, leather products, plastic films, celluloidmetal foils,

etc.
Paper type Paper sheets
Work theory Hydraulic







Computeriezd automatic continuously hydraulic cutting paper machine, paper cutter



Model

TSPC-920

TSPC-1150

TSPC-1300

TSPC-1370

Width of Cutting

920mm

1150mm

1300mm

1370mm

Max.Depth of Cutting

1050mm

1180mm

1300mm

1370mm

Mini Depth of Cutting

75mm

85mm

85mm

85mm

Max.Height of Cutting

130mm

130mm

130mm

130mm

Worktable height

900mm

900mm

900mm

900mm

Speed of Cutting

45time/min

45time/min

45time/min

45time/min

Max.Pressure on Paper

40000n

50000n

50000n

50000n

Main Motor Power

3Kw

4Kw

4Kw

4kw

Net Weight of Machine

3000kg

3800kg

4000kg

4500kg

Machine Dimension

2440*1600*1800mm

2850*1750*2000mm

3000*1750*2000mm

3100*1800*2000mm

Voltage of machine

380V, 3phase, 50Hz






hydraulic paper cutter

Computeriezd automatic continuously hydraulic cutting paper machine, paper cutter







Features of cutting paper machine

1.All lead screw and linear guide-rail makes paper impeller run smooth, low noise, accurate positioning, enhance the cutting precision and speed greatly, prolong the service lift of paper cutter.

2.The working tables are all chrome-plated and equipped with air balls which makes paper-pushing

easily and rusty-proof. Large side workingtable(1000*800) is optional.

3.IR photoelectric protection,buttons by two hands safety devices.

4.Safety device for knife bed, overloading protection for cutting, automatic return safety device.

5.Imported hydraulic components are adopted in hydraulic system,the pressure can be adjusted.The

paper is pressed twice by pressure-increased system.

6.Mechanical assistance device for knife replacement makes knife replaced quickly and safely.

7.Equipped with the optical knife alignment to make cutting more convenient.

8.PLC control system.

9.Ejecting device for knife bar.

10.Flat worm speed reducer transmission.

11.Inside electronic knife locker to make the cutting more safety and stable.

12.Multination langueage operation interface.

13.Carry on the block programming operation through the figures and diagrams operation manual.







Computeriezd automatic continuously hydraulic cutting paper machine, paper cutter







In order to quote you exact paper cuttting machine, please offer us following details:

1-What kind of machine do you want? Automatic or semi-automatic?

2-What is the width of your paper?







OUR SERVICE:



 1. Installation Services



Installation Services are available with all our new machines. We can send our technician

to your factory to help you install your purchased machines from our factory. Of course,

your factory need to supply the round trip tickets food, hotel and salary to our technician.





2. Clients Training Services



We advise each customer can send your own technician come to our factory to learn how

to operate our machines. We will let our technician teach and train your technician hand

by hand till he can operate our machine by himself.





3. After Sales Service



Our machine guarantee time is one year.



We will send many easy broken spare parts in the tool box together with machines.



If any parts broken, please take a pictures or a videos to us.







Computeriezd automatic continuously hydraulic cutting paper machine, paper cutter
