automatic polythene vest bag making machine
Features of polythene vest bag making machine | |
1. This polythene vest bag making machine is used to make T-shirt bag and vest bag only (can not make flat bag). Sealing, cutting, punching and conveying are done on one machine. |
2. There are two photocells, to make sealing and cutting more accurate in length. There is alarm from machine if tracking fail. |
|
3. The whole machine adopts microcomputer control and material-pulling by stepping motor (Servomotor control system can also be selected and equipped). |
4. The punching position for handles can be adjusted easily by chain system controlling. |
|
5. There are hot pins device, to make bag stack neat after cutting. |
6. Model and configuration of machine can be customized |
Model |
TSHQ-350×2 |
TSHQ-450×2 |
Max. bag making width |
300mm×2 |
400mm×2 |
Max. bag making length |
600mm |
650mm |
Bag making thickness |
0.01-0.05mm |
0.01-0.05mm |
Speed |
200-440pcs/min |
200-440pcs/min |
Air pressure |
5kg/cm2 |
5kg/cm2 |
Total power |
7kw |
9kw |
Machine weight |
1400kg |
1600kg |
Machine dimension |
6000×1400×1800mm |
6000×1600×1800mm |
polythene vest bag making machine
Products of polythene vest bag making machine are T-shirt bag only, both printed
and non-printed, can not make flat bags.
polythene vest bag making mahcine
Free spare parts with polythene vest bag making machine | ||
No. |
Spare parts |
Quantity |
1 |
Spring |
100pcs |
2 |
Teflon tape |
2pcs |
3 |
Blade heater |
4pcs(a set) |
4 |
Cutting blade |
2pcs(a set) |
5 |
Punch knife |
6pcs(three different sizes) |
6 |
Speed control board |
1pcs |
7 |
Electronic valve |
2pcs |
8 |
Tool box |
1pcs |
polythene vest bag making machine
Our default way of packaging is stretch film! Please remind us if you need wooden pallet or wooden case.
link doe more plastic bag making machine
In order to quote you exact plastic bag making machine, please offer us following details: |
1-What kind of plastic bag do you want to produce? |
2-What is the max width of plastic bag do you want to produce? |
3-What is the productivity of machine do you want? |
OUR SERVICE:
1. Installation Services
Installation Services are available with all our new machines. We can send our technician
to your factory to help you install your purchased machines from our factory. Of course,
your factory need to supply the round trip tickets food, hotel and salary to our technician.
2. Clients Training Services
We advise each customer can send your own technician come to our factory to learn how
to operate our machines. We will let our technician teach and train your technician hand by
hand till he can operate our machine by himself.
3. After Sales Service
Our machine guarantee time is one year.
We will send many easy broken spare parts in the tool box together with machines.
If any parts broken, please take a pictures or a videos to us.
