MASM06 Automatic Arrow Type Strapping Machine
1.Automatic Arrow Type Strapping Machine:
Machine Size: L3125*W740*H2485mm
PP/PET belt width: 16,19mm
Strapping speed : 25sec/belt
Machine Weight: 280kg/330kg
Power: 380v/50hz, 3-phase,2kw
2. Equipment Features:
1) The machine adopts imported PLC programmable controller and the man-machine interface display screen control system, which realizes integration of the machine electricity and gas. It has manual or automatic optional function.
2) Main strapping machine core or the whole machine can be moved back and forth with butt-joint type wear band, so it can realize the more reliable strapping on-line.
3) Modular framework and aluminum alloy belt make it more convenient to dismounting, install and adjust the machine. The host is equipped with exhaust system, which is much cleaner and more environmental.
4) Strapping belt can be adjustable at any time, so it is convenient to operate.
5) Malfunction of equipment is equipped with the fault alarm lamp, so when there is fault during production, it can automatically alarm and downtime.
Features For Pallet Strapping Machine
1.Automatic packaging;high work efficiency
2.Automatic warning system of low volume straps
3.For PP and PET strap
4.Cooling time adjustable
5.Auto strap tape guiding system
6.Auto alarm device
Main Electrical Parts(Pallet Strapping Machine)
♦Main motor:TWT of Taiwan
♦PLC: Mitsubishi of Japan
♦Packing motor:WANSHSIN of Taiwan
♦Movement motor:WANSHSIN of Taiwan
♦Position switch:OMRON of Japan
♦Relay:SCHNEIDER of France
♦Touch panel:WEINVIEW of Taiwan
♦Proximity switch:FOTEK of Taiwan
♦Photoelectric switch:SICK of Germany
♦Overheat protector:SCHNEIDER of France
♦Panel switch button:SCHNEIDER of France
Instruction For Pallet Strapping Machine
♦The machine is suitable for combined with conveyor line to using.
♦Width add to height than 2 meter that need to add a small motor for ensure the smooth strapping.(width and height is frame size).if than 3 meter need to add two small motors on frame.
♦Height must than 700mm of packing product.because adhesive part height is 580mm from the ground.
♦The machine is movement of mobile when strapping.it's mobile distance is 250mm to 400mm.
Our Factory:
MOTECH is leading provider of integrated packaging products and solutions for food,beverage,household goods and pharmaceutical industries.With over 20 years of experience Motech packaging provides a complete end-to-end packaging solution by offering state of-the-art packaging equipment, installation,training,service and supplies can be found a broad range of product industries, including:
•Automatic Production Line
•Boxing Machine
•Capping Machine
•Carton Machine
•Coding and Marking Machine
•Conveyor Equipment
•Counting Machine
•Filling
•Metal Detector
•Packing Machine
•Palletizer
•Robot
•Sealing Machine
•Shrink Wrapping Machine
•Strapping Machine
•Unscramber or Inserter Machine
•Weigher packaging Machine
