MOTECH's BU series Plastic Bottle Full-automatic Bottle Unscrambler are design to meet the the necessicity for the high speed filling plastic bottle line
Bottle unscrambler can perform the process from feeding disordered PET bottle to air conveyor of the filling machine in sequence to meet automatic production requirement of filling machine.
Features of these bottle unscrambler
1. PLC control, full-automatic working
2. Torque limit part is designed for the main motor reducer so as to protect the machinery if malfunctions occur.
3. Two put-casts in one cycle ensure that every work location should be with one bottle, which enhances bottle output efficiency.
4. The bottles are neck locked through the air conveyor so as to avoid Overturn in delivery.
5. Dilapidated bottles will be eliminated by a special device.
6. A lock detector is equipped for alarming; When locked, the machine will Automatically stop.
7. A photoelectric switch is set for starting when there is no bottle and stopping when there are bottles.
8. An oil pump will readily fill up the gears, bearings and the cams
9. Maintenance doors and mould replacement door provided.
10. Machine outer tank and revolving tank and meet the bottle part are all Stainless steel AISI304. Frame part adopts high-grade carbon jointing.
(we also provide Bottle Depalletizer, Bottle Palletizer)
Technical Parameter of Model MD-12Bottle Unscrambler
| Model | MD-12 |
| Working heads | 12 pieces |
| Speed | 6000 bottles per hour on 500ml pet bottle |
| Required Air pressure | 0.7MPA |
| Air consumption | 1.8M³ /min |
| Applicable plastic bottle size | diameter 50-96mm bottle height: 150-310mm |
| Drive motot | 1.5kw 1pc |
| Bottle Elevator motor | 0.75kw 1pc |
| Power supply | 220~415 3 or single phase available |
| Dimension | 2100mm in diameter, highness: 2300 |
| Weight | About 2800kgs |
