paper and cardboard thickness tester
It is applying to test the thickness of paper and cardboard.
Standard:
ISO 534:2005: Paper and board -Determination of thickness, density and specific volume
ISO 438:1980. Paper -- Determination of bulking thickness and apparent density
GB/T451.3: paper and board-Determination of thickness
Technical characters:
1, Measure range: 0-6mm,
2. indicator display range: 0-12.7mm
3, Accuracy: 0.001mm or 0.01mm (paper board)
4, Measuring area: 200mm²
5, Pressure: 100 Kpa,
6, Value error: ±2.5um or ±0.5%
7, Dimension: 80×120×120 (mm)
8, Weight: 5kg
Cardboard type Thickness Meter is applying to test the thickness of cardboard.
Standard:
ISO 534:2005: Paper and board -Determination of thickness, density and specific volume
ISO 438:1980. Paper -- Determination of bulking thickness and apparent density
GB/T451.3: paper and board-Determination of thickness
Technical characters:
1, Measure range: 0-8mm,
2. indicator display range: 0-25mm.
3, Accuracy: 0.01mm
4, Measuring area: 200mm² (dia. 16.6mm) for paper board,
1000 mm² for corrugated board.
5, Pressure: 100 Kpa, for paper board
20Kpa, for corrugated board.
6, Value error: ±2.5um or ±0.5%
7, Dimension: 80×120×120 (mm)
8, Weight: 10kg
