flexible cables VV YJV VV22 YJV22 VV32 Cable
POWER CABLE
XLPE INSULATED POWER CABLE
COPPER(ALUMINMU)CONDUCTOR XLPE INSULATED PVC SHEATHED POWER CABLE RATED VOLTAGE UP TO 35KV
Brief introduction about XLPE Insulated Power cable
Cross-linked polyethylene insulated power cable do not only has excellent electric, mechanical proper-ties,but also has powerful resistance against chemical corrosion,heat resistance and environmental stress resistance. Its structure is simple,the long period operating temperature is +90°C. It is convenient to use and can be laid with no restriction of different level.
APPLICATION
XLPE insulated power cables has a number of advantages over paper insulated and PVC insulated cable.XLPE cable has high electric strength, mechanical strength,high-ageing resisting,environmental stress resisting anti-chemical corrossion,and it is simple construction, using convenient and higher operating of long term temperature. It can be laid with no drop restriction.
Various of flame-retardant and non-flame retardant XLPE cable can be manufactured with three technology(peroxide,silance and irradiation crosslinking). The flame-retardant cable covers all kinds of low-smoke low-halogen,low-smoke halogen free,and non-smoke nonhalogenated and three slasses of A,B,C.
We can produce the cables as per GN, IEC,BS,VDE, AS/NZS,ICEA,JIS.
TYPE |
|
VOLTAGE |
|||
|
No.of cores |
0.6/1kV |
6/6kV, 6/10kV |
8.7/15kV, 12/20kV, 18/30kV |
19/33kV, 26/35kV |
|
|
Mm² |
|||
COPPER/XLPE/PVC |
1 |
1.5~800 |
25~800 |
35~1200 |
50~1200 |
AL/XLPE/PVC |
|
2.5~1000 |
25~1000 |
35~1200 |
50~1200 |
COPPER/XLPE/SWA (STA,AWA)/PVC |
|
10~1000 |
25~1000 |
35~1200 |
50~1200 |
COPPER/XLPE/PVC |
3 |
1.5~400 |
25~400 |
35~400 |
50~400 |
AL/XLPE/PVC |
|
2.5~400 |
25~400 |
35~400 |
50~400 |
AOPPER/XLPE/AWA (STA)/PVC |
|
4~400 |
25~400 |
35~400 |
50~400 |
